S C S E R I E S E N C L O S U R E S
N E M A 1 S C R E W C O V E R W A L L - M O U N T
A3
www.hubbell-wiegmann.com
Data Subject To Change Without Notice
SC121804
SC121804NK
SC121804G
SC121804GNK
16/16
Yes
18.00x12.00x4.00
B-A-F-F-A-B
A-B-A-F-F-A-B-A
(457x305x102)
SC122404
SC122404NK
SC122404G
SC122404GNK
16/16
Yes
24.00x12.00x4.00
B-A-F-F-A-B
A-B-A-F-F-A-B-A
(610x305x102)
SC151504
SC151504NK
SC151504G
SC151504GNK
16/16
Yes
15.00x15.00x4.00
A-B-A-F-F-A-B-A
A-B-A-F-F-A-B-A
(381x381x102)
SC151804
SC151804NK
SC151804G
SC151804GNK
16/16
Yes
18.00x15.00x4.00
A-B-A-F-F-A-B-A
A-B-A-F-F-A-B-A
(457x381x102)
SC181804
SC181804NK
SC181804G
SC181804GNK
16/16
Yes
18.00x18.00x4.00
A-B-A-F-F-A-B-A
A-B-A-F-F-A-B-A
(457x457x102)
SC182404
SC182404NK
SC182404G
SC182404GNK
16/16
Yes
24.00x18.00x4.00
A-B-A-F-F-A-B-A
A-B-A-F-F-A-B-A
(610x457x102)
SC183004
SC183004NK
SC183004G
SC183004GNK
16/16
Yes
30.00x18.00x4.00
A-B-A-F-F-A-B-A
A-B-A-F-F-A-B-A
(762x457x102)
SC242404
SC242404NK
SC242404G
SC242404GNK
14/14
Yes
24.00x24.00x4.00
A-B-A-F-F-A-B-A
A-B-A-F-F-A-B-A
(610x610x102)
SC060606
SC060606NK
SC060606G
SC060606GNK
16/16
Yes
6.00x6.00x6.00
A-B-A
A-B-A
(152x152x152)
SC060806
SC060806NK
SC060806G
SC060806GNK
16/16
Yes
8.00x6.00x6.00
A-B-A
A-B-A
(203x152x152)
SC061206
SC061206NK
SC061206G
SC061206GNK
16/16
Yes
12.00x6.00x6.00
A-B-A
B-A-F-F-A-B
(305x152x152)
SC080806
SC080806NK
SC080806G
SC080806GNK
16/16
Yes
8.00x8.00x6.00
A-B-A
A-B-A
(203x203x152)
SC081006
SC081006NK
SC081006G
SC081006GNK
16/16
Yes
10.00x8.00x6.00
A-B-A
B-A-F-F-A
(254x203x152)
SC081206
SC081206NK
SC081206G
SC081206GNK
16/16
Yes
12.00x8.00x6.00
A-B-A
B-A-F-F-A-B
(305x203x152)
SC101006
SC101006NK
SC101006G
SC101006GNK
16/16
Yes
10.00x10.00x6.00
B-A-F-F-A
B-A-F-F-A
(254x254x152)
SC101206
SC101206NK
SC101206G
SC101206GNK
16/16
Yes
12.00x10.00x6.00
B-A-F-F-A
B-A-F-F-A-B
(305x254x152)
SC121206
SC121206NK
SC121206G
SC121206GNK
16/16
Yes
12.00x12.00x6.00
B-A-F-F-A-B
B-A-F-F-A-B
(305x305x152)
SC121506
SC121506NK
SC121506G
SC121506GNK
16/16
Yes
15.00x12.00x6.00
B-A-F-F-A-B
A-B-A-F-F-A-B-A
(381x305x152)
SC121806
SC121806NK
SC121806G
SC121806GNK
16/16
Yes
18.00x12.00x6.00
B-A-F-F-A-B
A-B-A-F-F-A-B-A
(457x305x152)
SC122406
SC122406NK
SC122406G
SC122406GNK
16/16
Yes
24.00x12.00x6.00
B-A-F-F-A-B
A-B-A-F-F-A-B-A
(610x305x152)
S C S E R I E S S C R E W C O V E R P U L L B O X E N C L O S U R E S ( C O N T. )
Continued on page A4
1.63
1.63
1.63
1.63
1.94
1.63
1.63
1.63
1.94
1.63
1.63
1.63
1.63
1.63
1.94
1.63
1.63
1.63
A -- 1/2" TO 3/4"
B -- 3/4" TO 1"
F -- 1" TO 1-1/4"
A
A
B
A
B
A
A
F
F
B
B
A
F
A
A
B
A
F
A
B
A
15", 18", 24",
30" & 36" SIDE.
12" SIDE
10" SIDE
6" & 8" SIDE
4" SIDE
Knockout Patterns
F
F
H
D
INSIDE
0.63 TYP
Ø0.28 TYP
1.56 TYP
1.56 TYP
W
Note: 8", 10" and 12" deep
enclosures do not have mounting
embosses in back of enclosure,
only mounting holes.
1.56 TYP
2.06 TYP
Ø0.28 TYP
2.06 TYP
1.31 TYP
Ø0.28 TYP
4.00" X 4.00" MOUNTING
4.00" X 6.00" MOUNTING
CATALOG NUMBER
BODY/DOOR
COVERS
ENCLOSURE SIZE
PAINTED
GALVANIZED
STEEL
ONLY
KNOCKOUT PATTERN
W/KNOCKOUTS W/O KNOCKOUTS W/KNOCKOUTS W/O KNOCKOUTS
GAUGE
See Page A5
H+
1
⁄
8
", W+
1
⁄
8
", D+
3
⁄
16
"
WIDTH SIDE
HEIGHT SIDE
Note: Must specify CSA Label when ordering.
Consult factory for dimensions and drawings
on 8", 10" and 12" deep enclosures.
