N 1 C S E R I E S E N C L O S U R E S
“ L A R G E ” N E M A 1 H I N G E D W A L L - M O U N T
A12
F E AT U R E S - S P E C I F I C AT I O N S
Applications
Designed for use in control and
instrumentation applications in areas
which do not require oil-tight and
dust-tight specifications.
Construction
• Bodies and doors fabricated from
14 gauge steel
• Continuous hinged doors
• Doors are easily removable by
pulling the hinge pin
Industry Standards
UL 508, Type 1
CSA Certified, Type 1
NEMA/EEMAC Type 1
U L F i l e E 6 9 2 4
C S A F i l e L L 6 6 0 7 8
www.hubbell-wiegmann.com
Data Subject To Change Without Notice
CATALOG BODY/DOOR ENCLOSURE SIZE BACK PANEL BACK PANEL BACK PANEL
NUMBER STEEL GAUGE H X W X D CATALOG NUMBER* STEEL GAUGE SIZE A X B
N 1 C 3 0 4 2 0 9 1 4 / 1 4 4 2 . 0 0 x 3 0 . 0 0 x 8 . 9 4 ( 1 0 6 7 x 7 6 2 x 2 2 7 ) N P 4 2 3 0 1 2 3 9 . 0 0 x 2 7 . 0 0 ( 9 9 1 x 6 8 6 )
N 1 C 3 6 4 2 0 9 1 4 / 1 4 4 2 . 0 0 x 3 6 . 0 0 x 8 . 9 4 ( 1 0 6 7 x 9 1 4 x 2 2 7 ) N P 4 2 3 6 1 2 3 9 . 0 0 x 3 3 . 0 0 ( 9 9 1 x 8 3 8 )
N 1 C 3 6 4 8 0 9 1 4 / 1 4 4 8 . 0 0 x 3 6 . 0 0 x 8 . 9 4 ( 1 2 1 9 x 9 1 4 x 2 2 7 ) N P 4 8 3 6 1 2 4 5 . 0 0 x 3 3 . 0 0 ( 1 1 4 3 x 8 3 8 )
N 1 C 3 6 4 8 1 1 1 4 / 1 4 4 8 . 0 0 x 3 6 . 0 0 x 1 0 . 9 4 ( 1 2 1 9 x 9 1 4 x 2 7 8 ) N P 4 8 3 6 1 2 4 5 . 0 0 x 3 3 . 0 0 ( 1 1 4 3 x 8 3 8 )
N 1 C 3 0 4 2 1 3 1 4 / 1 4 4 2 . 0 0 x 3 0 . 0 0 x 1 2 . 9 4 ( 1 0 6 7 x 7 6 2 x 3 2 9 ) N P 4 2 3 0 1 2 3 9 . 0 0 x 2 7 . 0 0 ( 9 9 1 x 6 8 6 )
N 1 C 3 6 4 8 1 7 1 4 / 1 4 4 8 . 0 0 x 3 6 . 0 0 x 1 7 . 2 5 ( 1 2 1 9 x 9 1 4 x 4 3 8 ) N P 4 8 3 6 1 2 4 5 . 0 0 x 3 3 . 0 0 ( 1 1 4 3 x 8 3 8 )
“ L A R G E ” N 1 C S E R I E S H I N G E C O V E R E N C L O S U R E S
* Back panels must be ordered separately
NOTE: Second numerical value of catalog # represents height.
N1C304209
• Door and body stiffeners provided
for extra rigidity in larger enclosures
• Collar studs provided for mounting
optional back panels
• External mounting feet provided
• Grounding provisions provided
• Doors are furnished standard with
flushmount quarter-turn latch
Finish
• ANSI-61 gray polyester powder
inside and out
• Optional panels are white polyester
powder
Accessories
• Back panels (reference tables) and
page I4
• See pages J1-J22
