N 1 C S E R I E S E N C L O S U R E S
“ M E D I U M ” N E M A 1 H I N G E D W A L L - M O U N T
www.hubbell-wiegmann.com
Data Subject To Change Without Notice
BACK PANEL PERFORATED
CATALOG BODY/DOOR ENCLOSURE SIZE
CATALOG SUBPANEL
BACK PANEL BACK PANEL
E F G I K L
NUMBER STEEL GAUGE H X W X D
NUMBER** PART NUMBER**
SIZE A X B STEEL GAUGE
N1C121606LP* 14/14
16.00x12.00x6.75
N1P1216L N1P1216LPP
13.00x10.50
14
13.88 7.00 2.50 1.06 5.974 1.50
(406x305x171) (330x267) (352) (178) (64) (27) (152) (38)
N1C161606LP* 14/14
16.00x16.00x6.75
N1P1616 N1P1616PP
13.00x14.50
14
13.88 11.00 2.50 1.06 5.974 1.50
(406x406x171) (330x368) (352) (279) (64) (27) (152) (38)
N1C162006LP* 14/14
20.00x16.00x6.75
N1P1620 N1P1620PP
17.00x14.50
14
17.88 11.00 2.50 1.06 5.974 1.50
(508x406x171) (432x368) (454) (279) (64) (27) (152) (38)
N1C162406LP* 14/14
24.00x16.00x6.75
N1P1624 N1P1624PP
21.00x14.50
14
21.88 11.00 2.50 1.06 5.974 1.50
(610x406x171) (533x368) (556) (279) (64) (27) (152) (38)
N1C201606LP* 14/14
16.00x20.00x6.75
N1P2016 N1P2016PP
13.00x18.50
14
13.88 15.00 2.50 1.06 5.974 1.50
(406x508x171) (330x470) (352) (381) (64) (27) (152) (38)
N1C202006LP* 14/14
20.00x20.00x6.75
N1P2020 N1P2020PP
17.00x18.50
14
17.88 15.00 2.50 1.06 5.974 1.50
(508x508x171) (432x470) (454) (381) (64) (27) (152) (38)
N1C202406LP* 14/14
24.00x20.00x6.75
N1P2024 N1P2024PP
21.00x18.50
14
21.88 15.00 2.50 1.06 5.974 1.50
(610x508x171) (533x470) (556) (381) (64) (27) (152) (38)
N1C242406LP* 14/14
24.00x24.00x6.75
N1P2424 N1P2424PP
21.00x22.50
12
21.88 19.00 2.50 1.06 5.952 1.50
(610x610x171) (533x572) (556) (483) (64) (27) (151) (38)
N1C203006LP* 14/14
30.00x20.00x6.63
N1P2030 N1P2030PP
26.00x18.50
12
27.50 12.75 3.63 1.25 5.827 2.00
(762x508x168) (660x470) (699) (324) (92) (32) (148) (51)
N1C243006LP 14/14
30.00x24.00x6.63
N1P2430 N1P2430PP
26.00x22.50
12
27.50 16.75 3.63 1.25 5.827 2.00
(762x610x168) (660x572) (699) (425) (92) (32) (148) (51)
N1C243606LP 14/14
36.00x24.00x6.63
N1P2436 N1P2436PP
32.00x22.50
12
33.50 16.75 3.63 1.25 5.827 2.00
(914x610x168) (813x572) (851) (425) (92) (32) (148) (51)
N1C303606LP 14/14
36.00x30.00x6.63
N1P3036 N1P3036PP
32.00x28.50
12
33.50 22.75 3.63 1.25 5.827 2.00
(914x762x168) (813x724) (851) (578) (92) (32) (148) (51)
N1C121608LP* 14/14
16.00x12.00x8.75
N1P1216L N1P1216LPP
13.00x10.50
14
13.88 7.00 2.50 1.06 7.974 1.50
(406x305x222) (330x267) (352) (178) (64) (27) (203) (38)
N1C162008LP* 14/14
20.00x16.00x8.75
N1P1620 N1P1620PP
17.00x14.50
14
17.88 11.00 2.50 1.06 7.974 1.50
(508x406x222) (432x368) (454) (279) (64) (27) (203) (38)
N1C202008LP* 14/14
20.00x20.00x8.75
N1P2020 N1P2020PP
17.00x18.50
14
17.88 15.00 2.50 1.06 7.974 1.50
(508x508x222) (432x470) (454) (381) (64) (27) (203) (38)
N1C202408LP* 14/14
24.00x20.00x8.75
N1P2024 N1P2024PP
21.00x18.50
14
21.88 15.00 2.50 1.06 7.974 1.50
(610x508x222) (533x470) (556) (381) (64) (27) (203) (38)
N1C242008LP* 14/14
20.00x24.00x8.75
N1P2420 N1P2420PP
17.00x22.50
14
17.88 19.00 2.50 1.06 7.974 1.50
(508x610x222) (432x572) (454) (483) (64) (27) (203) (38)
N1C242408LP* 14/14
24.00x24.00x8.75
N1P2424 N1P2424PP
21.00x22.50
12
21.88 19.00 2.50 1.06 7.952 1.50
(610x610x222) (533x572) (556) (483) (64) (27) (202) (38)
N1C243008LP 14/14
30.00x24.00x8.63
N1P2430 N1P2430PP
26.00x22.50
12
27.50 16.75 3.63 1.25 7.827 2.00
(762x610x219) (660x572) (699) (425) (92) (32) (199) (51)
N1C303008LP 14/14
30.00x30.00x8.63
N1P3030 N1P3030PP
26.00x28.50
12
27.50 22.75 3.63 1.25 7.827 2.00
(762x762x219) (660x724) (699) (578) (92) (32) (199) (51)
N1C243608LP 14/14
36.00x24.00x8.63
N1P2436 N1P2436PP
32.00x22.50
12
33.50 16.75 3.63 1.25 7.827 2.00
(914x610x219) (813x572) (851) (425) (92) (32) (199) (51)
N1C303608LP 14/14
36.00x30.00x8.63
N1P3036 N1P3036PP
32.00x28.50
12
33.50 22.75 3.63 1.25 7.827 2.00
(914x762x219) (813x724) (851) (578) (92) (32) (199) (51)
N1C202410LP* 14/14
24.00x20.00x10.75
N1P2024 N1P2024PP
21.00x18.50
14
21.88 15.00 2.50 1.06 9.974 1.50
(610x508x273) (533x470) (556) (381) (64) (27) (253) (38)
N1C243010LP 14/14
30.00x24.00x10.63
N1P2430 N1P2430PP
26.00x22.50
12
27.50 16.75 3.63 1.25 9.827 2.00
(762x610x270) (660x572) (699) (425) (92) (32) (250) (51)
N1C242412LP* 14/14
24.00x24.00x12.75
N1P2424 N1P2424PP
21.00x22.50
12
21.88 19.00 2.50 1.06 11.952 1.50
(610x610x324) (533x572) (556) (483) (64) (27) (304) (38)
N 1 C 2 4 3 0 1 2 L P 14/14
30.00x24.00x12.63
N 1 P 2 4 3 0 N 1 P 2 4 3 0 P P
26.00x22.50
12
27.50 16.75 3.63 1.25 11.827 2.00
(762x610x321) (660x572) (699) (425) (92) (32) (300) (51)
N 1 C 3 0 3 6 1 2 L P 14/14
36.00x30.00x12.63
N 1 P 3 0 3 6 N 1 P 3 0 3 6 P P
32.00x28.50
12
33.50 22.75 3.63 1.25 11.827 2.00
(914x762x321) (813x724) (851) (578) (92) (32) (300) (51)
“ M E D I U M ” N 1 C S E R I E S H I N G E C O V E R E N C L O S U R E S
A11
*See note 1 on the drawing.
**Back panels must be ordered separately
NOTE: Second numerical value of catalog # represents height.
