Versa-Matic Versa-Surge Surge Suppressors for Air-Driven Diaphragm Pumps Metallic - Manual (Page 6)

versassmsm-rev0510 Page 4 Models VTA1, VTA25, VTA1½, VTA40, VTA2, VTA50, VTA3 & VTA80
4.60 117
7.75 197
9.27 235
3.88 98
11.20 284
1.12 28
15.13 384
FULLY
EXTENDED
13.87 352
FULLY
CLOSED
1/4" NPT Air Inlet
FLUID PORT
1" NPT
1" BSP
CENTERED
1/4" NPT DRAIN PORT
18.20 462
FULLY
CLOSED
15.37 390
11.38 289
3.19 81
5.69 144
20.67 525
FULLY
EXTENDED
4.60 117
FLUID PORT
1 1/2" NPT
1 1/2" BSP
CENTERED
1/4" NPT Air Inlet
Model VTA1½
Air Inlet
¼" NPT (external) fitting
FLUID Port - 1½" NPT
Model VTA40
Air Inlet
¼" NPT (external) fitting
FLUID Port - 1½" BSP
tapered thread
Model VTA1
Air Inlet
¼" NPT (external) fitting
FLUID Port - 1" NPT
Model VTA25
Air Inlet
¼" NPT (external) fitting
FLUID Port - 1" BSP
tapered thread
All Dimensions ± .13" (3mm)
