Versa-Matic 2 V Series Clamped Metallic (V2) - Manual (Page 17)

v2mdlAsm-rev0314
www
.
versamatic
.
com Model V2 Metallic Bolted •
14
Composite repair Parts list - rubber
Notes:
1.) The outer diaphragm plate material is to match the water chamber material (Cast Iron dome fitted pumps are to use SVB226 outer diaphragm plate)
2.) This metallic seat material is to match the water chamber material. In addition to this seat, (4) V240T o-rings are needed.
3.) V=Aluminum, SV=Stainless Steel, WV=Cast Iron, H =Hastelloy
Air Valve Assembly
Item # Qty. Description
Part Number
Without Oil Bottle With Oil Bottle
1 - Valve Body ASY (includes items 5-12) V20ALF V220A
2 1 Oil Bottle N/A V220D
3 1 Oil Bottle Pipe Plug N/A V220DP
4 1 Lubricator Rod N/A V220C
5 1 Valve Body 20ALF 220A
6 1 Valve Spool V220PST
7 1 End Cap with Guide PV220R
8 1 End Cap without Guide PV220S
9 2 Snap Ring V220T
10 1 Air Valve Gasket V220B
11 1 Reducer Bushing V220AP
12 1 Air Valve Screen V220E
13 4 Air Valve Mounting Bolt V220AS
Center Section Assembly
Item # Qty. Description Part Number
14 - Center Block ASY (Includes items 15-16) V220H
15 1 Center Block V220H-F
16 5 Main Shaft O-Ring V220J
17 2 Air Chamber V222B
18 2 Center Block Gasket V220P
19 3 Bolt V222C
20 3 Cone Nut (not pictured) V222D
21 1 Muffler Elbow PV220G
22 1 Muffler VTM-6
Diaphragm Assembly / Elastomers
Item # Qty. Description
Part Number
Versa-Rugged Versa-Dome
23 1 Main Shaft V221A
24 2 Diaphragm (See Below Material Chart) V224xx V225xx
25 2 O-ring V221D N/A
26 2 Inner Diaphragm Plate V221B V226B
27 2 Outer Diaphragm Plate (See Note 1 Below) VB221, WVB221, SVB221, HVB221 VB226,SVB226, HVB226
28 4 Valve Seat (See Below Material Chart) V240xx
29 4 Valve Seat O-Ring (See Below Material Chart) See Note 2
30 4 Valve Ball (See Below Material Chart) V241xx
Wet End Assembly
Item # Qty. Description
Part Number
Aluminum Cast Iron Stainless Steel Hastelloy
31 1 Water Chamber V235 WV235 SV235 HV235
32 2 Large Clamp Assembly V230 SV230
33
1 Discharge Manifold V236 WV236 SV236 HV236
1 Discharge Manifold (BSP Option) V236BSP WV236BSP SV236BSP HV236BSP
34
1 Suction Manifold (Footed Option) V237F WV237F SV237F HV237F
1 Suction Manifold (BSP Footed Option) V237FBSP WV237FBSP SV237FBSP HV237FBSP
35 1 Suction Manifold (Screen Mount Option) V237 N/A N/A N/A
36 1 Screen (Screen Mount Only) V238 N/A N/A N/A
37 3 Bolt (Screen Mount Only) V238A N/A N/A N/A
38 1 Hook Up Cover (Screen Mount Only) V242 N/A N/A N/A
39 4 Small Clamp Assembly V239 SV239
Elastomer Material Specifications
Material Versa-Rugged Diaphragm P/N
Versa-Dome
Diaphragm P/N
"Ball P/N" Seat P/N Seat O-Ring
Neoprene V224N V225N V241N V240N N/A
Buna Nitrile V224BN V225BN V241BN V240BN N/A
Viton V224VT V225VT V241VT V240VT N/A
Nordel V224ND V225ND V241ND V240ND N/A
PTFE N/A N/A V241TF V240TF V240T
Santoprene V224TPEXL V225TPEXL V241TPEXL V240TPEXL N/A
Hytrel V224TPEFG V225TPEFG V241TPEFG V240TPEFG N/A
Geolast V224G N/A V241G V240G N/A
Aluminum N/A N/A N/A V240A (See Note 2) N/A
Carbon Steel N/A N/A N/A V240CS (See Note 2) N/A
Stainless Steel N/A N/A V241SS SV240 (See Note 2) N/A
Hastelloy N/A N/A N/A HV240 (See Note 2) N/A
3: EXP
VIEW
