Versa-Matic 2 V Series Clamped Metallic (V2) - Manual (Page 15)

v2mdlAsm-rev0314
www
.
versamatic
.
com Model V2 Metallic Bolted •
12
Composite repair Parts list - PTfE
Notes:
1.) The outer diaphragm plate material is to match the water chamber material (Cast Iron Uses SV221TO)
2.) This metallic seat material is to match the water chamber material. In addition to this seat, (4) o-rings are needed. (Ref Note 3)
3.) These (4) o-rings are only used with metallic fitted seats.
4.) Only Cast Iron uses back-up diaphragm p/n V224TFB-1
5.) V=Aluminum, SV=Stainless Steel, WV=Cast Iron, H =Hastelloy
Air Valve Assembly
Item # Qty. Description
Part Number
Without Oil Bottle With Oil Bottle
1 - Valve Body ASY (includes items 5-12) V20ALF V220A
2 1 Oil Bottle N/A V220D
3 1 Oil Bottle Pipe Plug N/A V220DP
4 1 Lubricator Rod N/A V220C
5 1 Valve Body 20ALF 220A
6 1 Valve Spool V220PST
7 1 End Cap with Guide PV220R
8 1 End Cap without Guide PV220S
9 2 Snap Ring V220T
10 1 Air Valve Gasket V220B
11 1 Reducer Bushing V220AP
12 1 Air Valve Screen V220E
13 4 Air Valve Mounting Bolt V220AS
Center Section Assembly
Item # Qty. Description Part Number
14 - Center Block ASY (Includes items 15-16) V220H
15 1 Center Block V220H-F
16 5 Main Shaft O-Ring V220J
17 2 Air Chamber V222B
18 2 Center Block Gasket V220P
19 3 Bolt V222C
20 3 Cone Nut (not pictured) V222D
21 1 Muffler Elbow PV220G
22 1 Muffler VTM-6
Diaphragm Assembly / Elastomers
Item # Qty. Description Part Number
23 1 Main Shaft SV221AT
24 2 Main Shaft Stud V221F
25 2 Diaphragm V224TF
26 2 Back-Up Diaphragm (See Note 4 Below) V224TFB, V224TFB-1
27 2 Inner Diaphragm Plate V221TI
28 2 Outer Diaphragm Plate (See Note 1 Below) V221TO,SV221TO, HV221TO
29 4 Valve Seat (See Below Material Chart) V240xx
30 4 Valve Seat O-Ring (See Below Material Chart) V240T (See Note 3)
31 4 Valve Ball (See Below Material Chart) V241xx
Wet End Assembly
Item # Qty. Description
Part Number
Aluminum Cast Iron Stainless Steel Hastelloy
32 1 Water Chamber V235 WV235 SV235 HV235
33 2 Large Clamp Assembly V230 SV230
34
1 Discharge Manifold V236 WV236 SV236 HV236
1 Discharge Manifold (BSP Option) V236BSP WV236BSP SV236BSP HV236BSP
35
1 Suction Manifold (Footed Option) V237F WV237F SV237F HV237F
1 Suction Manifold (BSP Footed Option) V237FBSP WV237FBSP SV237FBSP HV237FBSP
36 1 Suction Manifold (Screen Mount Option) V237 N/A N/A N/A
37 1 Screen (Screen Mount Only) V238 N/A N/A N/A
38 3 Bolt (Screen Mount Only) V238A N/A N/A N/A
39 1 Hook Up Cover (Screen Mount Only) V242 N/A N/A N/A
40 4 Small Clamp Assembly V239 SV239
Elastomer Material Specifications
Material "Ball P/N" Seat P/N
PTFE V241TF V240TF
Aluminum N/A V240A (See Note 2 Below)
Carbon Steel N/A V240CS (See Note 2 Below)
Stainless Steel V241SS SV240 (See Note 2 Below)
Hastelloy N/A HV240 (See Note 2 Below)
MODEL SPECIFIC
3: EXP
VIEW
