Dimensional drawings, Re3 bolted – Versa-Matic 3 Bolted Metallic Hazardous Service Ball Valve (RE3) User Manual
Page 7
4.38
111
25.12
638
23.87
606
32.38
822
Discharge Flange conforms to both
ANSI 150# and DIN #80 Standards
Inlet Flange conforms to both
ANSI 150# and DIN #80 Standards
1" Female NPT
Air Line
Connection
36.31 ***
922
18.01
457
28.23
717
7.05
179
13.16
334
7.05
179
22.56
573
32.38
822
14.00 *
356
16.00 **
406
10.00
254
11.00
279
4X .60
15
re3mdlAsmATEX-rev0614
www
.
versamatic
.
com
1: PUMP
SPECS
Model RE3 Metallic Bolted •
4
RE3 Bolted
Dimensions in inches (mm dimensions in brackets)
The dimensions on this drawing are for reference only. A certified drawing can be requested if physical dimensions are needed.
Dimensional Drawings
Model Specific
