Versa-Matic 3 Bolted Metallic Hazardous Service Ball Valve (RE3) - Manual (Page 18)

re3mdlAsmATEX-rev0614
www
.
versamatic
.
com
3: EXP
VIEW
15
• Model RE3 Metallic Bolted
Composite Repair Parts List
DIAPHRAGM ASSEMBLY
Item Qty Description Dome Rugged PTFE Bonded PTFE 2-Piece
43 2 Each Washer, Spacer P126-0071 P126-0071 and 901.V003.330 P126-0071 P126-0071
44 1 Main Shaft P34-103 P34-103 P34-103 P34-103
45 2 Inner Diaphragm Plate P126-0027 V302C P126-0028 P126-0028
46 2 Outer Diaphragm Plate VB307 SVB307/HVB307 V302B 612.V002.110/ 612.V002.112 V302TO SV302TO
HV302TO
V302TO SV-
302TO HV302TO
47 2 Diaphragm V306XX (refer to material chart) V305XX (refer to material chart) V305TX V305TF-FB
48 12 Cap Screw, Dia Plate N/A V302G N/A N/A
49 12 Washer, Dia Plate N/A V302GA N/A N/A
50 2 Back-up Diaphragm N/A N/A N/A V305TFB
51 2 Bumper Washer P34-501 P34-501 P34-501 P34-501
52 2 Probe Tip 846.001.167 846.001.167 846.001.167 E46.001.167
53 2 Probe Tip O-Ring 560.201.360 560.201.360 560.201.360 560.201.360
54 2 Sensor O-Ring 560.033.360 560.033.360 560.033.360 560.033.360
55 2 Main Shaft O-Ring P34-403 P34-403 P34-403 P34-403
Item Qty Description Aluminum Stainless Steel Hastelloy C
56 2 Water Chamber V350FB SV350FB HV350FB
57 20 Water Chamber Bolt V387A SV387A SV387A
58 20 Wetted Section Washer V387B SV387B SV387B
59 20 Wetted Section Nut V387C SV387C SV387
60 4 Valve Seat V456XX(refer to material chart)
61 4 Valve Seat O-Ring SV456TES-1 (only used with metal seats)
62 4 Valve Ball V455XX (refer to material chart)
Option 1: 3 PC Center Port
63 2 Discharge Manifold Elbow V351E-FB N/A N/A
64 2 Inlet Manifold Elbow V352E-FB N/A N/A
65 2 Manifold Tee V358FB N/A N/A
66 4 Manifold Tee O-ring V258XX (refer to material chart) N/A N/A
67 32 Manifold Bolt V387D SV387D SV387D
68 32 Manifold Washer V387B SV387B SV387B
69 32 Manifold Nut V387C SV387C SV387C
Option 2: 1 PC Center Port
70 1 Discharge Manifold N/A SV351FB HV351FB
71 1 Inlet Manifold N/A SV352FB HV352FB
72 16 Manifold Bolt N/A SV387A SV387A
73 16 Manifold Washer N/A SV387B SV387B
74 16 Manifold Nut N/A SV387C SV387C
75 2 Mounting Bracket N/A SP55-390 SP55-390
76 4 Valve Seat O-Ring SV456TES-2 (only used with metal seats
DIAPHRAGM MATERIAL CODES
Suffix Codes
N Neoprene
BN Nitrile
VT FKM
ND EPDM
TF PTFE
XL/TPEXL Santoprene
FG/TPEFG Hytrel
G Geolast
BALL MATERIAL CODES
Suffix Codes
N Neoprene
BN Nitrile
VT FKM
ND EPDM
TF PTFE
XL/TPEXL Santoprene
FG/TPEFG Hytrel
G Geolast
P Polyurethane
A Acetal
Prefix Codes
S Stainless Steel
SEAT MATERIAL CODES
Suffix Codes
N Neoprene
BN Nitrile
VT FKM
ND EPDM
TF PTFE
XL/TPEXL Santoprene
FG/TPEFG Hytrel
G Geolast
P Polyurethane
A Acetal
CS Carbon Steel
Prefix Codes
S Stainless Steel
H Hastelloy
