Model U2 Metallic Bolted •
12
Composite repair & maintenance Kits
AIR VALVE KIT: U2 AV KIT
Part #
Description
Qty.
P98-104A
Valve Spool O-Ring
2
E200J
Valve Gasket
1
E200G
Air Diverter
1
E200H
Valve Insert
1
PILOT VALVE KIT: U2 PV Kit
Part #
Description
Qty.
P24-107
Pilot Shaft O-Ring
6
P24-106P
Pilot Shaft Spacer
5
P24-108
Stop Nut
2
P24-403
Main Shaft O-Ring
2
MAINTENANCE KIT — Rubber: U2-CMK-RB-PMB
Part #
Description
Qty.
P24-107
Pilot Shaft O-Ring
6
P24-106P
Pilot Shaft Spacer
5
P24-108
Stop Nut
2
E200J
Valve Gasket
1
P24-103
Main Shaft
1
E203A
Pilot Shaft
1
E200B ASY
Valve Spool Assembly
1
E201B-L ASY Shaft Retainer Assembly
1
E201B-R ASY Shaft Retainer Assembly
1
V20AEM
Muffler
1
E201B-5
Exhaust Valve O-Ring
2
E200J-1
Muffler Gasket
1
E201MB
Bushing
2
E201B-3
Retainer Plate Seal
2
E201M-1
Exhaust Sleeve O-Rings
2
E201D ASY
Exhaust Valve Assembly
2
MAINTENANCE KIT — PTFE: U2-CMK-TF-PMB
Part #
Description
Qty.
P24-107
Pilot Shaft O-Ring
6
P24-106P
Pilot Shaft Spacer
5
P24-108
Stop Nut
2
E200J
Valve Gasket
1
P24-102
Main Shaft
1
E203A
Pilot Shaft
1
E200B ASY
Valve Spool Assembly
1
E201B-L ASY Shaft Retainer Assembly
1
E201B-R ASY Shaft Retainer Assembly
1
V20AEM
Muffler
1
E201B-5
Exhaust Valve O-Ring
2
E200J-1
Muffler Gasket
1
E201MB
Bushing
2
E201B-3
Retainer Plate Seal
2
E201M-1
Exhaust Sleeve O-Rings
2
E201D ASY
Exhaust Valve Assembly
2
3: EXP
VIEW
