Versa-Matic 2 Ultra-Matic Bolted - Manual (Page 12)

u2msmMB-rev0314
www
.
versamatic
.
com 9
• Model U2 Metallic Bolted
Composite repair Parts list
AIR VALVE ASSEMBLY
Item Description Qty Standard: Polypropylene
Air Valve Assembly 1 E200
(Includes items 1-10)
1 Valve Body
1 E200A
2 Valve Spool Assembly 1 E200B ASY (Includes U-Cups)
3 Valve Spool U-Cup 2 P98-104A
4 End Cap Assembly 2 E500D ASY (Includes O-Rings)
5 End Cap Staple 2 E500F
6 Staple Retainer 2 E200L
7 Air Diverter 1 E200G
8 Valve Insert 1 E200H
9 Valve Gasket 1 E200J
10 Valve Cap Screw 4 P24-209
AIR END ASSEMBLY
Item Description Qty Standard: Polypropylene/Aluminum
15 Center Section 1 E201B
16 Bushing 2 E201MB
17 Pilot Shaft 1 E203A
18 Pilot Shaft Spacer 5 P24-106P
19 Pilot Shaft O-Ring 6 P24-107
20 Stop Nut 2 P24-108
21 Shaft Retainer – Left 1 E201B-L ASY (Includes O-Rings)
22 Shaft Retainer – Right (not shown) 1 E201B-R ASY (Includes O-Rings)
23 Exhaust Sleeve O-Ring 2 560.013.360
24 Shaft Retainer Screw 2 10-050
25 Exhaust Valve 2 E202 ASY
26 Shaft Retainer O-Ring 2 E201B-5
27 Retainer Plate Seal 2 P34-403
28 Muffler Plate 1 E201H
29 Muffler Plate Gasket 1 E200J-1
30 Muffler Plate Cap Screw 4 E201G
31 Muffler Elbow 1 PE201N
32 Muffler 1 V20AEM
DIAPHRAGM ASSEMBLY
Item Description Qty DOME PTFE Bonded PTFE 2-Piece
40 Main Shaft 1 P24-103 P24-102 P24-102
42 Inner Diaphragm Plate 2 V226B SV226B V221T SV221TI V221TI SV221TI
V226BTC V226BNP V221TITC V221TINP V221TITC V221TINP
43 Outer Diaphragm Plate 2 SVB226 HV226B SV221TO HV221TO SV221TO HV221TO
45 Diaphragm 2 V227BN V227N V227ND V227TX V227
V227VT V227TPEXL V227TPEFG
46 Back-up Diaphragm 2 N/A N/A V227TFB
WET END ASSEMBLY
Item Description Qty Stnd: Stainless Option 1: Cast Iron Option 2: Hastelloy
50 Water Chamber 2 SV235FB WV235FB HV235FB
51 Water Chamber Bolt 12 SV185A SV185A SV185A
52 Water Chamber Washer 20 SV189C SV189C SV189C
53 Valve Seat 4 V240BN V240CS V240N V240ND V240TF V240TPEFG V240TPEXL V240VT SV240 HV240
54 Valve Seat O-Ring (not shown) 8 V240T (USE WITH V240CS, SV240 AND HV240 SEATS)
55 Valve Ball 4 V241BN V241N V241ND V241P V241TF V241TPEXL V241TPEFG V241VT
Port Option 1: Vertical Discharge
56 Discharge Manifold 1 SV236FB WV236FB N/A
57 Inlet Manifold 1 SV237FB N/A N/A
58 Manifold Bolt 16 SV189D N/A N/A
59 Manifold Washer 16 SV189C N/A N/A
60 Manifold Nut 16 SV185B N/A N/A
Port Option 2: Horizontal
61 Discharge Manifold 1 SV236F-BH SV236FB-H HV236FB-H
62 Inlet Manifold 1 SV237FB-H WV237FB-H HV237FB-H
63 Manifold Bolt 16 SV189D SV189D SV189D
64 Manifold Washer 16 SV189C SV189C SV189C
65 Manifold Nut 16 SV185B SV185B SV185B
3: EXP
VIEW
