INSTALLATION INSTRUCTIONS
AH SERIES LOUDSPEAKERS
8", 12", AND 15"
4
AH SERIES LOUDSPEAKER SYSTEMS
Thank you for your purchase of an Atlas Sound AH
Series loudspeaker system. We have designed this
product to be a reliable and versatile solution to your
needs for years to come.
All models in the AH Series feature high output,
outstanding pattern control and amazing low
frequency response for indoor and outdoor
applications including football stadiums, sports
arenas, baseball fi
elds, and large auditoriums.
A variety of 8", 12", and 15" models are offered to
ensure that most any seating area or speaker to
loudspeaker distance may be accommodated.
All units feature effi
cient low frequency woofers
and a coaxial mounted 1" exit compression drivers
to provide excellent frequency response. A highly
effi
cient internal passive crossover network insures
proper transition between the (2) drivers.
FEATURES
• Impressive effi
ciency ratings exceeding 100dB
1Watt/1Meter (model dependent) makes the
AH series a perfect choice for high energy music
playback at sporting events as well as extended
range speech reinforcement.
• Weather & rodent resistant. Multiple mesh screens
over the front of the main horn protect the speaker
from weather and/or rodent damage.
• Easy installation. Heavy duty stainless steel
mounting bracket is included.
APPLICATIONS
The
AH Series is ideal for stadiums, outdoor fi
elds,
theaters, auditoriums, and convention center spaces
and may be used for paging, announcements,
background/foreground music, and/or internal
communications.
8" - AH99-8ST, AH94-8ST, and AH66-8ST
12" - AH99-12ST, AH94-12ST, and AH66-12ST
15" - AH5040S, AH9040S, and AH6565S
