• Avoid high temperatures.
• Allow for sufficient heat dispersion when installed on a rack.
• Handle the power cord carefully.
• Hold the plug when unplugging the cord.
• Keep the set free from moisture, water, and dust.
• Unplug the power cord when not using the set for long periods of time.
• Do not obstruct the ventilation holes. (For sets with ventilation holes.)
• Do not let foreign objects in the set.
• Do not let insecticides, benzene, and thinner come in contact with the set.
• Never disassemble or modify the set in any way.
• 8 times over sampling 1 bit D/A converter
Digital Output - For transfer of digital data
• 3 in. / 8 cm CD singles compatible
•
•
•
Fader Q Start control - For use with all compatable
American DJ Q-Start mixers
• 3 different speed scan
• Flip Flop - After Player A's track or entire CD is done, CD
Player B will instantly cue and play its track or entire CD
• Plays CD Recordables
• Dual Voltage Settings
• Frame search
• Loop Playback Mode
• Auto cue
• Anti-Skip - built in anti skip mechanism
• 30 tracks program play
Pitch display
DRIVE TRANSPORT UNIT FRONT PANEL
FIGURE 1
GENERAL NOTES ON USE
MAIN FEATURES
American DJ
®
POWER
DISC 1
1
OP/CL
DISC 2
2
OP/CL
American DJ ® AUDIO • DCD-PRO200MKIII™ INSTRUCTIONS MANUAL • PAGE 5
1. POWER (Power ON/OFF Button)
2. Player 1 Transport Tray.
3. Player 1 Open/Close Button
4. Player 2 Open/Close Button
5. Player 2 Transport Tray
6. Player 2 Remote Connector
7. Player 2 Digital Output - (S/PDIF - 75/Ohm)
8. Player 2 RCA Output
9. Voltage Selector Switch 10. Power Connection
11. Player 1 Remote Connector
12. Player 1 Digital Output - (S/PDIF - 75/Ohm)
13. Player 1 RCA Output
FUNCTIONS & CONTROLS
2 5 4 3 1
DRIVE TRANSPORT UNIT REAR PANEL
FIGURE 2
