Otter Outdoors Super XSR ATV Trailer - Manual (Page 4)

Page 4
5. Attach the tipper latch (Item 6) to the tongue (Item 4) with 3/8 x 3 bolts (Item 17) and nylon lock nuts (Item 16).
6. Attach the tongue bracket (Item 5) to the trailer (Item 1) with 3/8 x 1 bolts (Item 15), 3/8 washer (Item 20) and 3/8
nylon lock nuts (Item 16).
Bolt comes through front top side
of trailer. A section of the trailer
was removed for clarity.
5
16
15
1
20
17
6
4
16
