cotter-pins are installed in side-rail pins. Make sure that at least one leg of

cotter-pin is bent to 90 degrees.

Note: the front brackets run parallel to the front of the trailer and are used to

store/carry trailer ramps.

STEP 8: MOUNT TRAILER RAMPS & INSTALL REAR GATE

a. Mount the trailer ramps (5) on the front corner brackets, and secure the

ramps to the brackets by sliding the ramp pin-bolts through the eyeholes on

each end of the ramps.

b. Secure the ramps to the brackets by inserting the cotter-pins from the

retaining cables.

c. Position the rear gate (11) so that the gate’s pin-slots sit in-between the pin-

slots on the trailer frame.

d. Connect the gate’s pin-slots with those on the trailer using the gate-pins (F).
e. Secure the gate-pins with the cotter-pins, and then secure the cotter-pins by

bending at least one leg to 90 degrees.

YOU ARE FINISHED! We hope that you enjoy your NORTHSTAR TRAILER. Please

[email protected]

if you have any

questions. Our business hours are Monday-Friday 9:00 a.m. to 5:00 p.m. MST.

TRAILER SPECIFICATIONS

Trailer Weight: 670 lbs.

GVWR: 3000 Lbs

Length (w/ tongue): 184”
Width: 84”

Tire Size: 13x185
