Lincoln Electric IM279 LT-7 LINCOLDWELD Tractor - Manual (Page 53)

1 Button Head Socket Screw T11551-2 1 X
2 Wheel Scraper T8456 2 X
3 Cross Beam (D1) (Std. Tractor) M12673 1 X
3 Cross Beam Assembly, Includes: (Track Model Only) S17630 1 X
Mast Pad S15808-1 1 X
Arm M12673 1 X
4 Cross Seam Assembly (F3) M12671 1 X
5 Cam Block Spacer Pad T13673 1 X
6 Reed Switch Assembly (3CR), Includes: S13920-1 1 X
Reed Switch S12334-15 1 X
Energizer M11688 1 X
7 Shunt M12667 1 X
8 Cable Strain Relief Ring (A4) (Not Shown) S15181 1 X
9 Tractor Drive Assembly, Includes: (A1) (Below Code 9100) M12682 1 X
9 Tractor Drive Assembly, Includes: (A1) (Above Code 9100) M15341 1 X
9A Drive Motor and Gear Box (Below Code 9100) M12348-1 ø 1 X
9B Brush and Spring Assembly M12348-1B 2 X
9C Brush Cap M12348-1C ø 2 X
9A Drive Motor and Gear Box (Above Code 9100) M15340 1 X
9B Brush and Spring Assembly M15340-B 2 X
9C Brush Cap M15340-C 2 X
9D Pinion Gear S15208 1 X
9E Roll Pin T9967-3 1 X
10 Drive Gear Guard M12865 1 X
11 Frame Assembly (Below Code 7675) L5279 1 X
11 Frame Assembly (Above Code 7675) L5685 1 X
12 Reel Side Shield S15210 1 X
13 Reel Bottom Shield (A7) S15216 1 X
14 Nozzle Cable (Std. Tractor) M12700-1 1 X
14 Nozzle Cable (Track Model Only) M12700-2 1 X
15 Mast (F1) (Below Code 8000) S15814 1 X
15 Vertical Head Lift Adjuster (F1) (Above Code 8000) M13334-1 1 X
Vertical Head Lift Adjuster Parts See P-117-O
16 Clamp Arm (D2), Includes:Hardware (Not Shown) S15194 1 X
16A Upper Jaw and Arm M12672 1 X
16B Lower Jaw S15193 1 X
17 Front Wheel Assembly (D) (Std. Tractor) M12669 1 X
17 Front Wheel Assembly (D) (Track Model Only) M14813 1 X
Wheel Assembly Parts See P-117-G
18 Shunt Cover L5278 1 X
19 Shunt Insulation S15170 1 X
20 Shunt Shield S15430 1 X
21 Steering Extension Arm T13733 1 X
10-28-2003
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-117-C.1 P-117-C.1
# Indicates a Change This Printing
ø
This part is obsolete and no longer available.
#
