A-1 INSTALLATION
BIG RED™ 500
A-1
TECHNICAL SPECIFICATIONS - BIG RED™ 500 (K2810-1)
Make/Model Description Speed (RPM) Displacement Starting Capacities
System
Deutz 3 cylinder Idle 1890 125 cu. in 12VDC battery Fuel
D2011L03i 32HP (24 kw) (2.05L) & Starter (20 US gal)
Diesel Engine @ 1800 RPM Full Load 1800 75.7L
EPA Tier 4i Bore x Stroke
Compliant Oil:
3.89" x 4.13" 6.3 QTS.
(99mm x 105mm) 6.0L
INPUT - DIESEL ENGINE
1. Output rating in watts is equivalent to volt-amperes at unity power factor. Output voltage is within ± 10% at all loads up to
rated capacity. When welding, available auxiliary power will be reduced.
2. To Top of enclosure, add 9.63”(244.6mm) to top of exhaust pipe.
RATED OUTPUT @ 104° F (40° C) - WELDER
HEIGHT WIDTH DEPTH WEIGHT
36.87 (2) in. 28.28 in 65.1 in.
936.5 mm 718.3 mm 1653.5 mm
Welding Process
DC Constant Current
TIG
OUTLETS
1
1
1
Output Range
Amps
65A TO 500A
65A TO 250A
Max. Weld OCV
Voltage @ 1800RPM
90 Volts
75 Volts
Welding Output
Current/Voltage/Duty Cycle
400A / 36V / 100%
450A / 34V / 60%
500A / 30V / 40%
250A / 20V / 100%
VOLTS
120
120
240
AMPS
20
15
15
POWER
2400 Watts
1800 Watts
3600 Watts
Auxiliary Power 1
Single Phase 60 Hz AC
PHYSICAL DIMENSIONS
RATED OUTPUT @ 104° F (40° C) . - GENERATOR
1538 lbs. (697 kg.)
RECEPTACLES AUXILIARY POWER CIRCUIT BREAKER OTHER CIRCUIT BREAKERS
1 - 120VAC Duplex NEMA(5-20R) GFCI protected 1 - 20 AMP for 120 VAC Duplex (NEMA)
1 - 120VAC European (IEC-309)-GFCI protected 1 - 15 AMP for 120 VAC European (IEC-309)
20AMP for Battery Charging Circuit
1 - 240VAC European (IEC-309) 1 - 15 AMP for 240 VAC European (IEC-309)
RECEPTACLES AND CIRCUIT BREAKERS
