DESCRIPTION
This unit has a sealed lead acid battery and should be
kept fully charged at all times for maximum battery
life. Recharge when first received, immediately after
each use, and every three months if not used. Failure
to do this may cause the battery life to be greatly
reduced.
CONTROLS AND INDICATORS
(See Figure B.1)
B-1 OPERATION
JUMP STARTER
B-1
FIGURE B.1
Battery Level LEDs indicate state of charge
12Vdc socket for powering 12Vdc devices
Storage Holsters for
neat clamp storage
Red charging and
green charged LEDs
to monitor the
charging process
Automatic Internal Charger
charges internal battery
250 cranking amps help start
stubborn 12V motors
Storage Holsters for
neat clamp storage
USB Port for charging
5Vdc personal devices
such as cell phones,
cameras and tablets
On-Off switch with red (reverse)
and green (correct) hook-up LEDs
for safe hook-up to battery / chassis
