C-1 ACCESSORIES C-1
OPTIONAL EQUIPMENT
K857 – REMOTE CURRENT CONTROL
The K857 consists of a control box with 8.5 m (28 ft) of
four conductor cable and a 6 pin Amphenol for easy
connection to the front of the power source.
The K857 will give the same control as the current con-
trol on the machine depending on the position of the
current dial selector switch.
Extreme care must be observed when installing or
extending the wiring of a remote control. The
Remote Control cord can be lengthened to any
length by splicing four wires to the standard 28 ft
(8.5 m) cord before connecting to the R3R recep-
tacle. Only the green lead can and should be
grounded to the machine case.
K963 – HAND AMPTROL AND K870 FOOT
AMPTROL
Connect directly to the 6 pin Amphenol on the front of
the power source.
AMMETER AND VOLTMETER – (factory installed
only)
IDEALARC ® R3R-500-I
CAUTION
