AFL-08B-N270 User Manual
Page 30
Description Label Type
Clear CMOS J_COMS1 2-pin header
COM1 Pin 9 setting JP8 10-pin header
COM3 Pin 9 setting JP10 6-pin header
COM3 RX RS-232/422/485 select JP9 8-pin header
COM3 TX RS-422/485 select JP11 6-pin header
COM3 RS-232/422/485 select JP6 12-pin header
Table 2-1: Jumpers
2.5.1 Access the Jumpers
To access the jumpers, remove the back cover and aluminum inner cover. To remove the
back panel, please refer to Section 2.2.
2.5.2 Preconfigured Jumpers
WARNING:
Do not change the settings on the jumpers in described here. Doing so
may disable or damage the system.
The following jumpers are preconfigured for the AFL-08B-N270. Users should not change
these jumpers (Table 2-2).
Jumper Name Label Type
LVDS voltage selection J_VLVDS1 3-pin header
Touch Screen Select J1 4-pin header
Panel Type and Resolution J_LCD_TYPE1 10-pin header
Table 2-2: Preconfigured Jumpers
