5.3.11.1 Smart Fan Mode Configuration
Use the Smart Fan Mode Configuration submenu (BIOS Menu 16) to configure fan
temperature and speed settings.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
FAN1 Smart Fan Control [Manual Duty Mode]
Manual Duty Mode 60
FAN2 Smart Fan Control
[Manual Duty Mode]
Manual Duty Mode 60
Smart Fan Mode Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 16: Smart Fan Mode Configuration
FAN1/FAN2 Smart Fan Mode [Manual Duty Mode]
Use the FAN1/FAN2 Smart Fan Mode option to configure the system smart fans.
Manual Duty
Mode
D EFAULT The fan spins at the speed set in Manual Duty
Mode settings (below option)
Manual Duty Mode
Use the + or – key to change the value. Enter a decimal number between 0 and 100.
5.3.12 Serial Port Console Redirection
The Serial Port Console Redirection menu (BIOS Menu 17) allows the console
redirection options to be configured. Console redirection allows users to maintain a
system remotely by re-directing keyboard input and text output through the serial port.
