ICE-QM871 COM Express Module
Page 51
Enabled D EFAULT Legacy USB support enabled
Disabled Legacy USB support disabled
Auto Legacy USB support disabled if no USB devices are
connected
5.3.9 iWDD H/W Monitor
The iWDD H/W Monitor menu (BIOS Menu 11) displays the CPU temperature and CPU
fan speed, and contains the fan configuration submenu.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
PC Health Status
CPU temperature : +68 C
CPU_FAN1 Speed : 1878 RPM
VDDR
: +1.381 V
+VCC_CORE : +1.741 V
+1.05S : +1.070 V
+V1.5S : +1.501 V
+V1.8S : +1.815 V
+V3.3A : +2.997 V
+V5S : +5.048 V
VCC12 : +11.321 V
> Smart Fan Mode Configuration
Smart Fan Mode Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 11: iWDD H/W Monitor
PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
CPU Temperature
CPU Fan Speed
VDDR
+VCC_CORE
+1.05S
+V1.5S
