SPCIE-C2260-i2 PICMG 1.3 CPU Card

Page 69

Step 1:

Obtain the IP address of the managed system. It is recommended to use the

IPMI Tool on the managed system to obtain the IP address. To use IPMI Tool to

obtain IP address, follow the steps below:

a. Copy the Ipmitool.exe file to a bootable USB flash drive.

b. Insert the USB flash drive to the SPCIE-C2260-i2

c. The SPCIE-C2260-i2 boots from the USB flash drive

d. Enter the following command: ipmitool 20 30 02 01 03 00 00

(there is a space between each two-digit number)

e. A serial of number shows. The last four two-digit hexadecimal numbers are

the IP address. Convert the hexadecimal numbers to decimal numbers.

Step 2:

On the remote management console, open a web browser. Enter the managed

system IP address in the web browser (Figure 4-22).

Figure 4-22: IEI iMAN Web Address

Step 3:

The login page appears in the web browser.

Step 4:

Enter the user name and password to login the system. The default login

username and password are:

-Username: admin

-Password: admin

Step 5:

Press the login button to login the system.

Step 6:

The IEI iMAN Web Interface appears.
