Vfd control box - standard, Vfd control box w/fire suppression – XLT XD-9007A (ELEC Oven Version – C, AVI Hood Version – C) User Manual
Page 46
46
Technical Support US: 888-443-2751
Technical Support INTL: 316-943-2751
VFD Control Box (Cover removed)
VFD CONTROL BOX - STANDARD
VFD Control Box w/Fire Suppression
VFD Controller
Circuit Breaker
MUA Damper Relay (R4)
Terminal Strip (TS3)
Cooling Fan Relay (R1)
Exhaust Fan Fire Suppression Relay (R2)
Hood Lights Relay (R3)
MUA Damper Relay (R5)
MUA Damper Relay (R6)
