Conveyor Control Programming Procedure
OVEN SERVICE PROCEDURES
Configuration Key Functions
< L > =
Behind the in XLT is a hidden button. This is used along with the up and down
button to access the programming mode. Use this after each step to advance to the
next parameter when programming.
UP = Increases the setting of the selected parameter.
DOWN = Decrease the setting of the selected parameter.
1. Enter Programming Mode/Program the bake length
 Press the button and both and button simultaneously to enter
programming mode.
 0055 will appear on screen, this is already set from factory
 Press the button until the desired belt length is displayed. Belt lengths will read
as follows:
1832 = 0032
1855 = 0055
2440 = 0040
3240 = 0040
3255 = 0055
3855 = 0055
2. Program the Total Reduction Value - Press the button until the desired settings is
reached. All ovens = 300.
3. Set Speed Trimming Value - Press the button until the display shows 0000.
4. Set Fast Bake Limit - Press the button until the display shows 1:30.
5. Set Slow Bake Limit - Press the button until the display shows 17:00.
6. Set Conveyor Motor Rotation - Press the OR buttons until the display shows
1 for right-to-left direction, or 2 for left-to-right belt direction.
7. Save and Exit Programming Mode - Press the button two (2) times to save and exit Pro-
gramming Mode.
After leaving Program Mode, 1:30 run time will appear on the display. Press and hold the or
buttons until desired run time appears.
Read the entire instruction before programming.
TIP
