AVI HOOD ELECTRICAL CONNECTIONS
MUA Damper Relays - Multiple Output - Standard Voltage & Frequency
Supply from Breaker Panel
10 Amperes Maximum
TS 1
Some wiring removed for clarity. See schematic for details.
Neutral
TS 2
R3
A1
A2
Power
Power
A1
A2
Power
Power
A1
A2
Power
Power
R2
R1
MUA Unit Relay
Customer Supplied
MUA Unit Relay
Customer Supplied
MUA Unit Relay
Customer Supplied
