TECHNICAL DATA

Individual features of the 3 models:

Camera:

VZ-17

VZ-37

VZ-47

Built-in camera system:

1 CCD unit - 1/2" interline transfer

3 CCD unit - 1/2" interline transfer

Effective pixels:

752 x 582 (PAL models)
768 x 494 (NTSC models)

3 times 752 x 582 (PAL models)
3 times 768 x 494 (NTSC models)

3 times 782 x 582

Horizontal resolution:

> 470 lines

> 750 lines

> 800 lines

Vertical resolution:

> 400 lines (PAL models)
> 350 lines (NTSC models)

> 420 lines (PAL models)
> 370 lines (NTSC models)

> 575 lines

Color reproduction:

very good colors

100% lifelike colors

Signal format / horizontal
frequency / vertical frequency:

interlaced / 15.7 kHz / 50 Hz (PAL) or
60 HZ (NTSC)

non-interlaced / 31.25 kHz / 50 Hz

Images per second:

PAL: 50 fields (=half images)
NTSC: 60 fields (=half images)

50 frames (=full images)

S/N ratio:

50dB

58dB

Gain control:

automatic / manual 0 to 18 db

Electronic shutter:

off / step / manual

On screen menu:

for basic settings of the unit

for basic settings of the unit and
professional camera adjustments

Camera reset function:

yes

White balance:

one push white balance

automatic/3200K/5600K/manual/o.p.

Image freeze function:

yes

Connections:

RGBS-outputs:

1 x Video-RGBS (converted Y/C-
signal): 4 x BNC connectors, RGB: 0.7
Vpp 75

Ω,

Sync: 2 Vpp

1 x Video-RGBS (true RGB signal):
4 x BNC connectors, RGB: 0.7 Vpp
75

Ω,

Sync: 2 Vpp

switchable to component output (YUV)

2 x Data-RGBS (true RGB signal):
5 x BNC connectors and 15 Pin S-
VGA connector, RGB: 0.7 Vpp
75

Ω,

Sync: 2 Vpp

Component output (YUV)

Y, R-y, B-y, BNC connectors

Y/C (S-video) output:

4-pin connector and 2 x BNC
connector, Y-signal: 1 Vpp 75

Ω,

C-signal: 0.3 Vpp 75

Ω,

4-pin connector and 2 x BNC connector,
Y-signal: 1 Vpp 75

Ω,

C-signal: 0.3 Vpp

Ω,

Composite video output:

BNC connector, VBS 1.0 Vpp 75

Ω

BNC connector, VBS 1.0 Vpp 75

Ω

Preview output (outputs a signal
even when image is switched off):

Composite video, BNC connector, VBS
1.0 Vpp 75

Ω

Composite video, BNC connector, VBS
1.0 Vpp 75

Ω

Data-RGBS, 15 Pin S-VGA connector

Sync input:

BNC connector, composite video signal
or black burst (BB), VBS 1.0 Vpp
75

Ω,

H-phase and SC-phase

adjustable (manually)

BNC connector, composite video signal
or black burst (BB), VBS 1.0 Vpp
75

Ω,

H-phase and SC-phase adjustable

(with on screen menu)

Parallel port

(for external controlling)

yes

Serial port with extended serial
protocol including status report:

yes - RS 232

Common features of all 3 models:

Camera:

Iris:

automatic / manual

Text enhancement in color:

yes

Optical element:

Optics:

two telezoom lenses, f = 2.0

Zoom range (incl. mirror zoom):

12 x optical zoom (full resolution)

Max. pick-up area on working
surface:

360 x 270 mm (14.2" x 10.6")

Min. pick-up area on working
surface:

30 x 22 mm (1.2" x 0.9")

Maximum object height on working
surface:

250mm (9.8")

Max. object size when picked up
outside of working surface:

length, width and height to infinity

Depth of focus on small object
(42x32mm - 1.6"x1.3"):

70mm (2.8")

Depth of focus on large object
(360x270mm - 14.2"x10.6"):

250mm (9.8")

Reflection free area:

whole working surface

Synchronized lightfield (for easy
positioning of objects):

yes

Light element:

Light source:

12V / 100W halogen-lamp, 3200
Kelvin (constant light spectrum)

Spare lamp

in automatic lamp changer

Built-in lightbox:

Size: 380 x 280 (15" x 11")
Light source: 4 x CCFL

Laser center marker:

when working with lightbox or macro

Shadow free illumination:

yes

Illumination of hollow objects:

yes

Disturbing stray light:

none

General specifications:

Infrared remote control:

yes

Motorized arm:

yes - for up/down position and macro
zoom function

Motorized top mirror:

yes - for scrolling

Intelligent control panel:

yes - only available functions are
illuminated

Power-on preset:

on/off switchable

Programmable presets

3 (plus some additional through RS232)

Power consumption:

230 W

Power source:

Multi voltage 90-264 V AC, 50/60HZ

Made in:

Austria (EC)

Weight:

17 kg (36 lbs)

Specifications and availabilit y subject to change!
