A list of the most useful ftp commands is provided in Figure 8.
Doing an “ls” after connecting with FTP will show a number of files and directories. The
most important are shown in Figure 9.
WebNet The “operating system” itself.
autoexec Configuration file describing which scripts to run at
startup.
cgi-bin Root directory of dynamic webpages (WebScript
scripts)
etc Directory for configuration files
webpages Root directory for static webpages (html pages)
Figure 9: A list of the most important directories on the WebNet
4.1.3 Setup of FTP users
Figure 10: Setup of access rights for the FTP users
The privileges of the two FTP users “admin” and “anonymous” can be set up on the
“Configure FTP Access” page. For each user there is a Password field and a Root directory
field. The password field is self-explanatory, and the root directory field contains a path to
the directory that the user sees when he logs in via FTP. The user cannot “cd” backwards
(towards the root) from this directory.
18 WebNet User’s Guide
