PAGE 7 91728A0
Specification Data for the 2000
FEATURES
Pulling
Capacity
2000lbs. (907 kg) Brake Self-locking gear train (Rated
Load Holding)
Switch Type Remote Control Warranty 1 year limited
Motor Permanent Magnet Wire Rope 3/16" X 35' (10.7 m)
HP 1.6 HP 3.0" Diameter Drum Diameter 1 1/4 in. (3.18 cm)
Power 12 volt DC Fairlead Hawse
Gear Train Split Ring Gear Hole Pattern 2 Holes on 3.1" (7.87 cm)
center
Gear Ratio 153:1 Electrical Leads 2 – 6’ (1.8 m)
Clutch Knob – pull and turn Weight 18 lbs. (8.2 kg.)
Performance Data for the 2000
PERFORMANCE DATA: 2000
Load Current Speed Pulling Power by Wire Rope Layer
Lbs. Kg Amps Ft/min M/min Layer lbs. kg
0 0 6.7 7.2 2.2 1 2000 907
500 226.8 24.1 6.8 2.0 2 1504 683
1000 453.6 44.7 5.7 1.7 3 1348 612
1500 680.4 72.0 4.8 1.4 4 1222 555
2000 907 80.0 4.2 1.3 5 1117 507
Dimensional Data for the 2000
