S E R V I C E
ELECTRONIC COMPONENTS PARTS LIST
MODEL > 767, 1767, 1000, 1200-SK/III (
q u a n t i t i e s
P e r
c o m P a r t m e n t
)
ITEM
DESCRIPTION
PART NO. QTY ITEM
DESCRIPTION
PART NO. QTY
1
HI-LIMIT PROTECTION COVER
1003936
1
26
HEATSINK, THERMALLY COND . PAD
HE-33926
2
2
HEAT SINK
1005836
1
27
NUT, 10-32, NF HEX MS, #18-8 S/S
NU-2215
4
3
ACCESS COVER
1009990
1
28*
NUT, HEX #8-32
NU-2296
4
4
BONNET SPOT ASSBY 767, 1767
5010047
1
29
CONTROL PANEL OVERLAY, 767
PE-27178
1
BONNET SPOT ASSBY, 1000, 1200
5009280
1
CONTROL PANEL OVERLAY, 1767
PE-27181
1
5
BOARD, POWER SUPPLY
BA-33554
1
CONTROL PANEL OVERLAY, 1000
PE-29385
1
6
BOARD, ASSB, VOLTAGE MONITOR
BA-33764
1
CONTROL PANEL OVERLAY, 1200
PE-29386
1
7
T-BLOCK
BK-3019
1
30
3/8" HOLE PLUG
PG-25574
1
8
BEEPER
BP-3567
1
31
13/16" HOLE PLUG
PG-3589
2
9
BRACKET, TETHER
BT-26884
1
32
RELAY
RL-33558
2
10
1/2" HOLE BUSHING
BU-3006
2
33
RELAY, 230V, 25A, ZERO CROSSING
RL-33829
2
11
7/8" SNAP BUSHING, BLACK
BU-3007
1
34
10-32 X 1/4" PAN HD GROUND SCREW
SC-2190
1
12
1-1/8" SNAP BUSHING
BU-3378
6
35
SCREW, PAN HEAD M4 X 7MM
SC-22271
2
13
CONTROL, ASSB, COOK, HOLD
CC-34194
1
36
6-32 X 1/4" PAN HD
SC-22500
2
14*
CORDSET, 208-240V
CD-3607
1
37
8-32 X 2 SLOT PAN HEAD 18-8 S .S .
SC-23154
2
CORDSET, 230V
CD-3922
1
38
6-32 X 1-1/4" ROUND HD
SC-2365
2
15
CANOE CLIP
CL-22820
2
39
10-32 X 1/2" FLAT HEAD
SC-23670
4
16
CONNECTOR, 10 PIN
CR-33717
1
40
8-32 X 1/4" PHIL SCREW
SC-2459
5
17
CONNECTOR, 9 PIN
CR-33718
1
41
SCREW, 6-32 X 1/2", NC PHIL TRUSS
SC-2472
8
18
CONNECTOR, 8 PIN
CR-33719
1
42*
SELF TAPPING 8-32 X 1/2"
SC-25849
8
19
CONNECTOR, 7 PIN
CR-33761
1
43
SPACER, LOCK MOUNT PANEL
SP-33832
4
20
CONNECTOR, 6 PIN
CR-33762
1
44
SWITCH, CIRCUIT BREAKER, 30A
SW-34076
1
21
CONNECTOR, FERRULE #18
CR-34827
4
SWITCH, CIRCUIT BREAKER, 20A
SW-34077
1
22*
DATAKEY FOR CONTROL
DS-34823
1
45
T-STAT, 300 F HI-LIMIT
TT-33476
1
23
ELEMENT, SMOKE
EL-35022
2
46*
WASHER, #8 EXT LOCK
WS-2333
4
24
FAN, BOX
FA-34524
1
47
STAR LOCK WASHER
WS-2467
1
25
GASKET, 1/2" SELF ADHESIVE
GS-2019
1
CABLE HEATING KIT #4881
(
one
Per
comPartment
)
C
*
not
shown
DESCRIPTION
PART NO.
QTY
DESCRIPTION
PART NO.
QTY
CABLE HEATING ELEMENT
CB-3045
210 FT
STUD
ST-2439
12
RING CONNECTOR
CR-3226
12
HEX NUT
NU-2215
24
INSULATION CORNER
IN-3488
1 FT
INSULATING SLEEVE
SL-3063
12
SHOULDER BUSHING
BU-3105
12
ELECTRICAL TAPE
TA-3540
1 ROLL
CUP BUSHING
BU-3106
12
