S E R V I C E
EXTERIOR SERVICE PARTS LIST
A
*
not
shown
MODEL >
767-SK/III
1000-SK/III
ITEM
DESCRIPTION
PART NO. QTY PART NO. QTY
1
GUARD SENSOR
1493
1
1493
1
2
CHIP TRAY
4652R
1
4652R
1
2a
CHIP TRAY INSERT
1243
1
1243
1
3*
PROBE HOLDER
13239
1
13239
1
4
SHIM, LATCH
13947
1
13947
1
5
DRIP PAN
14831
1
5005616
1
6
CASTER SPACER
1007145
12
1007145
12
7
BACK CASING
1010393
1
1011878
1
8
BOTTOM PANEL
1010394
1
1009941
1
9
SIDE PANEL
1010395
2
1010575
2
10
BONNET, TOP COVER
1010401
1
1009951
1
11
ELEMENT COVER
1010409
1
1011813
1
12*
SMOKE HEATER PLATE WELD
5003782
1
5003782
1
13
PROBE COVER WELDMENT
5009712
1
5009712
1
14
INSULATION
IN-22364
1
IN-22364
1
15
DRIP TRAY KIT
5010391
1
5009716
1
DRIP TRAY
1010584
1
1010188
1
DRIP TRAY HOLDER
1010585
1
1010189
1
SCREWS
SC-2459
3
SC-2459
3
16
DOOR ASSEMBLY, RH
5011828
1
5012859
1
DOOR ASSEMBLY, LH
5011829
1
5012861
1
17
BONNET ASSBY, SPOT
5010047
1
5009280
1
18
BLOCK, MTG, SENSOR
BK-24427
1
BK-24427
1
19*
BLOCK, 2 TERMINAL, PORCELAIN
BK-33546
3
BK-33546
3
20*
BRACKET, CHIP TRAY
BT-29217
1
BT-29217
2
21
3/8" HOLE BUSHING, BLACK
BU-3419
1
BU-3419
1
22*
5/8" SNAP BUSHING, BLACK
BU-3611
1
BU-3611
1
23*
CABLE, SMOKE HEATER
EL-35022
1
EL-35022
1
24
CASTER, 3-1/2" RIGID
CS-25674
2
CS-25674
2
25
CASTER, 3-1/2" SWIVEL W/ BRAKE
CS-25675
2
CS-25675
2
26
COVER, HINGE
CV-22171
2
CV-22171
2
27*
GASKET ASSEMBLY, DOOR
GS-22951
1
GS-22952
1
28
GASKETS, ADHESIVE, .125 X .375 [lin ft]
GS-23622
1
GS-23622
1
29
HANDLE, OFFSET MAG LATCH
HD-27080
1
HD-27080
1
30
HINGE, 1-3/8 OFFSET, CHROME
HG-22338
1
HG-22338
1
31
INSULATION
IN-2003
1
IN-2003
1
32
RATING TAG LABEL
LA-26348
1
LA-26348
1
33*
NUT, 1/4-20 HEX S/S
NU-2437
4
NU-2437
4
34*
PANEL OVERLAY MENU CARD
PE-23384
1
PE-23384
1
35
PROBE ASSEMBLY
PR-34298
1
PR-34298
1
36
PROBE, RECEPTICAL
PR-34705
1
PR-34705
1
37
10-32 X 3/4 PHILLIPS PAN HD
SC-2071
2
SC-2071
2
38
SCREW, 10-32 X 3/4, NF, PHIL,FLAT M/S, #18-8 S/S
SC-2072
6
SC-2072
6
39
SCREW, 10-32 X 1-1/2, NF, PHIL,FLAT M/S, #18-8 S/S
SC-2073
10
SC-2073
10
40
SCREW, 6-32 X 1/2, NC PHIL,FLAT
SC-2239
2
SC-2239
2
41*
SCREW, 1/4-20 X 1/2, NC SLOT RND
SC-2332
4
SC-2332
4
42
8-32 x 1/4" PHIL SCREW
SC-2459
36
SC-2459
36
43
S/S WIRE SHELF
SH-2324
2
SH-2325
2
44*
S/S WIRE SHELF, RIB RACK
SH-2743
1
SH-29474
1
45
SENSOR, 1-3/4" L
SN-33541
1
SN-33541
1
46
SIDE RACK, STAINLESS STEEL
SR-28405
2
SR-2266
2
47
DOOR SWITCH, REED, SPST
SW-33559
1
SW-33559
1
48
CORD, 230V/50HZ ONLY
CD-3922
1
CD-3922
1
