Plunger Pumps
Operating Instructions and Parts Manual
RMV Series Pumps
Pos. Part # Description Qty. Pos. Part # Description Qty.
32 2840710 Oil plug 1
33 480480 O-Ring
Ø 4.48x1.78
2
34 1982520 Hose nipple 1
35 1250280 Ball 1
36 1560520 Spring 1
37 1460430 O-Ring
Ø 4x2.5
1
38 2840350 Jet 1
39 1343580 Spring 1
40 800560 O-Ring
Ø 8.73x1.78
2
41 2840340 Detergent injector 1
42 2840270 Suction fitting
3/4” NH
1
43 2840390 Suction fitting 1
44 1266330 Filter 1
46 2840400 Outlet fitting 1
48 2840060 Spring 3
49 2840530 Piston 3
50 2840050 Ring 3
51 1980130 Thrust washer 1
52 1980250 Bushing 1
53 1980240 Thrust washer 1
2840900 Hollow shaft
mr
1
54
2840730 Hollow shaft
ln
1
55 161060 Bearing 1
56 161050 Circlip
Ø i72
1
57 2840310 Seal 1
58 2840890 O-Ring
Ø 14x2
2
AR64545 Oil 1
O
il
C
apaCity
2.2
Oz
1 800220 Head bolt
M8x45 (221 in/lbs)
3
2840860 Pump head
ml
1
2
2840870 Pump head
rn
1
6 2840830 Plug 1
7 600180 O-Ring
Ø 7.66x1.78
1
8 2840130 Plug
(221 in/lbs)
3
9 740290 O-Ring
Ø 14x1.7
4
10 2849050 Complete valve 6
11 1470210 O-Ring
Ø 9x1
1
12 2840770 Seat 1
13 2840760 By-pass jet 1
14 820510 O-Ring
Ø 10.82x1.78
1
15 2840750 Piston guide 1
16 2760210 Ring 1
17 660190 O-Ring
Ø 6.07x1.78
1
18 2260100 O-Ring
Ø 6.02x2.62
1
19 2760400 Piston 1
20 1980300 Nut
M6
1
21 392840 Grub screw
M6x16
1
22 2760480 Handle insert 1
23 1980220 Plate spring 2
24 2760410 Spring 1
25 2200141 Gasket 6
26 770590 O-Ring
Ø 23.52x1.78 
3
2840561 Bushing
mr
3
2840090 Bushing
ln
3
27
2840550 Bushing

3
28 2840540 Bushing

3
29 1683500 Seal 3
30 2840230 Housing 1
31 480560 O-Ring
Ø 6.75x1.78
1
Legend
Ш
12
Ш
12
Ш
12
Ш
12
For m For l For r For n
RMV2G20 RMV2.5G20 RMV2G23B RMV2.5G23B
For  For 
RMV2G25 RMV2.5G25
