8

A

1585

1780

B

1450

1640

D

645

675

F

770

775

G

130

130

K

340

340

L

355

370

M

1505

1685

N

1505

1685

P

210

210

R

285

285

S

1280

1460

V

410

410

1

Cold water inlet

2

Hot water outlet

3

Gas control

4

Drain valve

5

T&P relief valve tapping

6

Clean out

Dimensions

BTI 85

BTI 100

1.3

Technical information

1.3.1 Dimensions

These water heaters are only suitable
for a flue tube with minimal the
announced diameter (dimension G).

All dimensions are given in mm. (rounded off on 5mm). See figur 3.
