Follow the steps below to measure the CT primary and secondary currents:

a. Connect the Safety Ground to the MCCB-250.

b. Connect the Current cables from the MCCB-250 to the bus (CT primary) as shown in

Figure 4.

c. Connect the CT secondary winding to the MCCB-250

[EXT CURRENT]

input as shown

in Figure 4.

d. Turn the

[CURRENT CONTROL]

knob to zero.

e. Turn on the

[POWER SWITCH]

.

f. Hold the

[DOWN ARROW]

key to momentarily turn on the current source.

g. Turn the

[CURRENT CONTROL]

knob to set the desired current.

h. Release the

[DOWN ARROW]

key.

i. Press the

[UP ARROW]

key to select the ON+TIMER mode and to start the test.

j. Observe and record the CT primary and secondary current and the polarity displayed on

the LCD screen. A typical LCD screen display is shown below:

NOTE

The external current polarity is shown as in phase (“+” sign) or out of phase
(“-”) with respect to the MCCB-250 drive current. The CT turns ratio can be
obtained by taking the current ratio.

k. Turn off the current source by pressing the

[DOWN ARROW]

key.



986 mS 59.2CY

Ext I:-1.004 A
Drv I:20.00A
