Model CT-3500

Operating Procedures
2
3.0 CT-3500 SPECIFICATION (Refer to the specification list in Table 1.)
Table 1. CT-3500 Specifications and Leading Particulars
MODEL CT-3500
TYPE Special-purpose utility test equipment ;
Digital Circuit-Breaker Timer
SIZE 15-inches Wide by 7-inches High by 13-inches Deep
WEIGHT Less than 15 pounds
INPUT POWER 90-120 or 220-240 volts ac (Selectable), 50/60Hz
DRY CONTACT INPUTS 3 channels (continuity detectors)
TRIGGER INPUT Open/Close: 24 to 300 V, dc/peak ac
OPERATIONS Open, Close, Open-Close, and Close-Open strokes
RESOLUTION ±1/10 millisecond
ACCURACY 0.1% of reading
±
0.1ms
DISPLAY LCD, back lighted, 4-line-by 20-character; alpha-numeric
CONTROLS Keypad, 10 alpha-numeric and 6 function pushbuttons
COMPUTER
INTERFACE
RS-232C
PRINTER Built-in thermal printer (prints on 2.5-inch-wide strip)
ENVIRONMENT Operating: 0ºC to 55ºC; Storage: -40ºC to 65ºC
SHIPPING CASE Optional (Hard case with foam liner)
WARRANTY One Year parts & labor; post-warranty service available
NOTE:
THE ABOVE SPECIFICATIONS ARE VALID AT NOMINAL OPERATING VOLTAGE AND AT A TEMPERATURE OF 25
°C (77°F)
THE CT-3500
 SPECIFICATIONS MAY BE UPGRADED AND CHANGED WITHOUT PRIOR NOTICE.
