Vanguard CT-3500 - Manual (Page 13)

Model CT-3500

Operating Procedures
9
repeat the A, B, C cycle.
Selections from the rest of the
alpha/numeric keys are done the
same. The 1 and 0 (zero) keys
have no alpha functions.
When a character is entered and
appears in the display at the
cursor position, the cursor is
advanced to the next position by
pressing the
∧
key or backed-
spaced by pressing the
∨
key. To
delete a character, press CLEAR.
When all character entries are
selected, press ENTER key to
load the identity data in storage
registers, and go to the next
prompt display.
d. On the Set-Up Menu, press number 1
(ENTER ID); the prompt COMPANY
displays (see below).
e. Key select characters of the utility
COMPANY name, then press ENTER.
The STATION prompt appears:
f. Key select characters of the STATION
name, then press ENTER. The CIRCUIT
prompt appears:
g. Key select characters of the CIRCUIT
name, then press ENTER. The
MANUFACTURER prompt appears:
h. Key select characters of the
MANUFACTURER name, then press
ENTER key. The MODEL prompt
appears:
i. Key select characters of the MODEL
name, then press ENTER key. The
SERIAL prompt appears:
j. Key select characters of the SERIAL
NUMBER, then press ENTER. The KVA
RATING prompt appears:
k. Key select characters of the KVA
RATING, then press ENTER. The
OPERATOR prompt appears:
l. Key select characters of OPERATOR
name, then press ENTER key. The
display returns to the START-UP MENU.
NOTE
Identification data should be entered for
each breaker that is tested
COMPANY:
STATION:
CIRCUIT:
MANUFACTURER:
MODEL:
SERIAL NUMBER:
KVA RATING:
OPERATOR:
