9
6. TECHNICAL SPECIFICATION
INPUT
Connectors
Impedance
Max input level
CMRR
Six balanced XLR,Two 1/4"TRS Instrument Inputs and TWO
combo on Channel One and Tw
Balanced >50Kohm, Unbalanced>25Kohm
>+24dBu balanced and unbalanced
Typically>60dB at 1KHz
OUTPUT
Connectors
Impedance
Max output level
Eight 1/4" TRS (INSERT)
DIRECT OUT MULTI -PIN CONNECTOR WIRING
Unbalanced>60ohm
>+21dBu unbalanced
SYSTEM SPECIFICATIONS
Bandwidth
Frequency Response
Signa/Noise
THD
Crosstalk
Stereo Coupling
20HZ to 20kHz, +0/-0.5dB
10Hz to 200kHz,+0/-3dB
>128dBu, weighted, 22Hz to 22kHz
<0.007%
<-100dB, 22Hz to 22Khz
True RMS detection
FUNCTION SWITCHES
48 Volt Phantom Power
High pass filter
Eight channel of the MP8 has 48V Phantom power available.
>80Hz
INDICATORS
INPUT LEVEL
Function switch
3 element LED display: -20 / 0 / CLIP dB.
LED indicator for each
POWER SUPPLY
Mains Voltages
Fuse
Power consumption
Mains Connection
USA/Canada
U.K./Australia
Europe
General Export Model
~120VAC, 60Hz
~240VAC, 50Hz
~230VAC, 50Hz
~100-120VAC,
~200-240VAC, 50-60Hz
100-120VAC : 400mA (SLOW-BLOW)
200-240VAC : 200mA (SLOW-BLOW)
30 Watts
Standard IEC receptacle
PHYSICAL
Dimension
Net Weight
W(483.0)*D(288.0)*H(44.2) mm
3.3Kg
