REV 2 ATRT-01 S2, ATRT-01B S2, AND ATRT-01D S2 USER’S MANUAL
25
Press the
[ENTER]
key. The following screen will be displayed:
Type the X winding name plate voltage value using the numeric keypad. The
screen will be updated as shown:
Press the [ENTER] key. Continue to step e.
2. NO
Press the
[2]
key (NO) if you do not want to enter the transformer name plate
voltage. Continue to step e.
e. The following screen will be displayed showing the Phase A cable connections for the
selected test (this will differ depending on the test):
Make the cable connections per the instructions and then press the [START] key to
run the Phase A test.
f. The following screen will be displayed while the test is being performed:
DYN 1 TRANSFORMER
PLEASE WAIT...
CABLE PHS-A XFMR
X1,X2 to X1,X0
H1,H2 to H1,H3
“START” TO RUN TEST
ENTER H WINDING
NAME-PLATE VOLTAGE:
10 V
ENTER X WINDING
NAME-PLATE VOLTAGE:
V
ENTER H WINDING
NAME-PLATE VOLTAGE:
500 V
