Page 8

background image

8

LINC Installation Instructions TG103062 Issue 2/C 21/11/06

LINC

Installation Instructions

Manufactured for and on behalf of the Environmental and Combustion Controls Division of Honeywell Technologies Sàrl, Ecublens, Route du Bois
37,Switzerland by its Authorized Representative, Trend Control Systems Limited.

Trend Control Systems Limited reserves the right to revise this publication from time to time and make changes to the content hereof
without obligation to notify any person of such revisions or changes.

Trend Control Systems Limited

P.O. Box 34, Horsham, West Sussex, RH12 2YF, UK. Tel:+44 (0)1403 211888 Fax:+44 (0)1403 241608 www.trend-controls.com

Trend Control Systems USA

6670 185th Avenue NE, Redmond, Washington 98052, USA. Tel: (425)897-3900, Fax: (425)869-8445 www.trend-controls.com

WEEE Directive :

At the end of their useful life the packaging
and product should be disposed of by a suitable
recycling centre.

Do not dispose of with normal household waste.
Do not burn.

3.2

Installation - Configuration

(Continued)

12

Note Neuron ID

addRess/ neuron chip id 00:00:00:00:00:00

13

Exit Configuration

X

Æ "Exit from Utility"

If user wishes to install LINC using
neuron ID - see step 14 a

a).

When installing LINC On lonworks tool
enter neuron ID from step 12 - or press
service button.

14

Install on LonWorks Network Management Tool (LMT)

J15

J11

J4

J14

J12

J9

J17

SE
RVIC

E

S3

J1

TX
RX

LON OK
LAN OK

D2
D3

1

2

4

8

16

32

64

19k

2

9K
6

1K
2

BAUD ADDRESS

sevice button

If

a

binding IQLs to LonMark Devices

or b

LINCs version <3.23 straddle router

or c

other devices have address conflicts with IQ system devices

or d

LONROUTERS used on system already installed on LMT

b).

The LINC network image can be retrieved by uploading
the XIF file from LINC to tool.

See LonWorks network management tool
manual. See IQ system LonWorks
Products Engineering Guide (TE200292).
Lonworks System Integrator must have
Lonworks engineering expertise.

15

Check LINC Operation

If LonWorks Internetwork (LINC address <100)

If Internetwork LonWorks Extension (LINC address =>100)

LINC

LINC

Lan

LonWorks

IQL

LONC

or

or

LINC

LINC

Lan

LonWorks

IQL

LONC

I/N

or

or

terse text comms

terse text comms

4 Disposal

If one IQ system LonWorks device is installed on LMT, all must be installed
Note that if a 3xtend/EINC L is installed in the LonWorks segment, IQ system devices cannot be installed on a LMT because
3xtend/EINC L does not support installation on a LMT.
