Water outlet connection
The end of the drain hose can be connected as follows:
1. To the sink outlet siphon, securing it if necessary with a clip.
2. Hooked over the edge of the sink using the special curved plastic guide
provided.
3. To a wall outlet provided with vent-hole, minimum internal diameter
4 cm.
The waste connection must be at a height of between 30 cm (minimum) and
100 cm (maximum) from the floor.
It makes no difference which way the drain hose faces, either to the right or
left of the dishwasher.
Avoid bending or kinking the hose as this could prevent or slow down the
discharge of water.
min 30 cm max 100 cm
min 4 cm
Ш 21
Ш 18
CS09
2 3 1
max 100 cm
