SWITCHERS
6
INSTALLING YOUR SWITCHER 6
Step 1. Make sure that the proper power adapter
is used. The Altinex power adapter is
supplied with the unit.
Step 2. Connect the power adapter to the power
port. The power indicator light and the
input lights should turn red.
Step 3. Remove the anti-static connector covers
and connect the cables from the computer
video card or from the video output of
other sources, to Input 1 or Input 2 of the
DA1916SX.
Step 4. Connect the cables from the output port
of the DA1916SX to the large screen
monitor or data projector.
Step 5. If the remote control switch is used,
connect the RC5203CC to the channel
select port.
Step 6. If a control system is used to control the
DA1916SX, connect the channel select
port of the DA1916SX to the relays port of
the control system.
Step 7. Verify that the picture quality on the
display is good. If a signal is not being
received, make sure that the display is
compatible with the resolution of the
computer graphics card.
CONGRATULATIONS! YOU ARE DONE.
OPERATION 7
The settings of the DA1916SX Switcher can be
adjusted using the auto-switch mode and the
manual switch mode as described in Section 4.
There are no other adjustments necessary to
operate the unit. The DA1916SX will operate
successfully as long as cables are attached
properly and other technical specifications are
followed.
ACCESSORIES 8
Model No. Description
RACK MOUNTING ACCESSORIES
DA1295RM Mount mini-brackets (2 – “L” shape)
CONTACT CLOSURE SWITCH
RC5203CC Contact Closure with 6 ft. cable
TERMINATION PLUG
MS8000TP VGA (15-pin HD) Termination Plug
ADAPTOR CABLE
MS8102CA 6 feet, 15-pin HD Male to 5 BNC Male
MS8104CA 15 feet, 15-pin HD Male to 5 BNC Male
MS8105CA 50 feet, 15-pin HD Male to 5 BNC Male
MS8106CA 6 feet, 15-pin HD Male to 5 BNC
Female
VGA CABLE MALE TO MALE
CB3703MR 3 feet, high resolution type cable
CB3706MR 6 feet, high resolution type cable
CB3715MR 15 feet, high resolution type cable
CB3725MR 25 feet, high resolution type cable
CB3750MR 50 feet, super high resolution type
cable
CB3775MR 75 feet, super high resolution cable
CB37100MR 100 feet, super high resolution cable
CB37150MR 150 feet, super high resolution cable
VGA CABLE MALE TO FEMALE
CB3903MR 3 feet, high resolution type cable
CB3906MR 6 feet, high resolution type cable
CB3915MR 15 feet, high resolution type cable
CB3925MR 25 feet, high resolution type cable
CB3950MR 50 feet, super high resolution type
cable
CB3975MR 75 feet, super high resolution type
cable
CB39100MR 100 feet, super high resolution type
cable
CB39150MR 150 feet, super high resolution type
cable
POWER ADAPTERS
PC5502US 9V 500mA Power Supply for US
PS5503US 9V 500mA Power Supply for US w/50 ft
wire
PS5512UK 9V 500mA Power Supply for UK
PS5522AU 9V 500mA Power Supply for Australia
PS5532GR 9V 500mA Power Supply for Germany
PS5542JP 9V 500mA Power Supply for Japan
If you experience any problems, please call
1-800-258-4623 or 1-714-990-2300 for
international calls.
