cause harmful interference in which case the
user will be required to correct the interference
at his own expense.
•
Any changes or modifications to the unit not
expressly approved by Altinex, Inc. could void
the user’s authority to operate the equipment.
ABOUT YOUR SWITCHER 2
The DA1916SX is a 2-in, 1-out VGA
(VGA/SVGA/XGA) Auto Switcher with manual
remote capability through the use of a contact
closure.
The DA1916SX automatically switches to the active
input source by sensing an incoming signal. If two
input signals are active simultaneously, the
DA1916SX will default to Input 2. Please note that
the DA1916SX may be custom modified at the
factory upon request so that it will default to Input 1
instead of Input 2.
The DA1916SX offers both a main output for the
selected source and a loop output that always
passes through Input 1, regardless of which input is
selected. The main output is fully buffered and, if it
is not used, it must be terminated with a 75 Ohms
VGA termination plug (part # MS8000TP), which is
supplied with the unit.
The DA1916SX can be controlled manually by
connecting the contact closure control to its 2.5mm
mini-coaxial remote control jack. The DA1916SX is
packaged with a small switch and a six foot cable
(part # RC5203CC), which controls the DA1916SX
or the contact closure may be made from a control
system. When the contact closure control is
connected to the DA1916SX, an open position will
select Input 1 and a closed position will select
Input 2.
Although the DA1916SX is designed primarily to
handle VGA-type (RGBHV) signals, it can also be
used to pass RGBS and RGsB. It may also be
used to pass composite video, s-video, and
component video signals through red, green, and
blue channels. This may require the use of adapter
cables to convert a 15-pin HD connector to BNC
connectors.
The DA1916SX is perfect for applications that use
wall or floor plates for auto switching. It also works
very well as a building block for classroom training
systems in which the instructor’s signal is placed
alongside a bus (via the loop output) to each of the
student’s stations. The students own computer is
connected to Input 2.
The DA1916SX may be mounted to furniture or
other suitable surfaces using optional hardware.
TECHNICAL SPECIFICATIONS 3
FEATURES/DESCRIPTION DA1916SX
GENERAL
Inputs
Two
Input Connector 15-pin HD Female
Outputs
Main Output Connectors
15-pin HD Female
(buffered)
Loop Output Connectors 15-pin HD Female
(loop)
Compatibility VGA via UXGA, RBHV,
RGBS, RGsB,
Component Video (Y,
R-Y, B-Y), S-Video
(Y/C), and Composite
Video
Table 1. DA1916X General
MECHANICAL DA1916SX
Material 0.1” Al
Finish Gray
Top Panel Lexan
Height (inches) 3.00in (76mm)
Width (inches) 4.38in (111mm)
Depth (inches) 1.00in (25mm)
Weight (pounds) 0.4lbs (0.18kg)
Ship Weight (pounds) 2.0lbs (0.91kg)
T
°
Operating 10
°
C-35
°
C
T
°
Maximum 50
°
C
Humidity 90
%
non-condensing
MTBF (calculations) 40,000 hrs (min.)
Table 2. DA1916SX Mechanical
ELECTRICAL DA1916SX
Input Video Signal
Analog Signal
1.5V p-p max
Impedance 75 Ohms
