9
Recorded and output signals of the MTS
broadcast
2
1
Playing back a MTS-program
recorded tape
Before starting
Set the VCR/CATV/DBS/TV selector to VCR.
Press MENU.
Press i or k to select SETUP, then press
ENTER/DISPLAY.
Press i or k to select AUDIO OUTPUT.
Note
You can also use the display window to check the broadcast
type.
When the VCR receives the stereo broadcast, ST appears.
When the VCR receives the SAP broadcast, SAP appears.
When the VCR receives the Bilingual broadcast, BIL appears.
CLOCK
PROGRAM
TUNING
SETUP
SELECT ENTER
TO EXIT PRESS
ENTER
MENU
FUNCTION OSD : ON
HI-FI
STEREO
STEREO
STEREO
LANGUAGE SELECT : ENGLISH
AUDIO MODE :
BROADCAST TYPE :
AUDIO OUTPUT :
AUDIO OUTPUT :
CHANNEL MAPPING
SELECT ADJUST
TO EXIT PRESS MENU
FUNCTION OSD : ON
HI-FI HI-FI
STEREO
STEREO
LANGUAGE SELECT : ENGLISH
AUDIO MODE :
AUDIO MODE :
BROADCAST TYPE :
AUDIO OUTPUT :
CHANNEL MAPPING
SELECT ADJUST
TO EXIT PRESS MENU
TV
screen
MONO
STEREO
SAP
STEREO/
SAP
Recorded signal
Broadcast
Mono
Stereo
Mono+SAP
Stereo+SAP
Signal output
from AUDIO
OUT
BROADCAST Hi-Fi Normal
TYPE track track LEFT RIGHT
STEREO Mono Mono Mono Mono
SAP Mono Mono Mono Mono
MONO Mono Mono Mono Mono
Left/
Left Right
STEREO Right Mono
channel channel
channel
Left/
Left Right
SAP Right Mono
channel channel
channel
MONO Mono Mono Mono Mono
STEREO Mono Mono Mono Mono
SAP SAP SAP SAP SAP
MONO Mono Mono Mono Mono
Left/
Left Right
STEREO Right Mono
channel channel
channel
SAP SAP SAP SAP SAP
MONO Mono Mono Mono Mono
4
26
Press j or l to select the audio output mode.
STEREO: The stereo sound is heard.
LEFT:
The left channel sound is heard from both
channels.
RIGHT: The right channel sound is heard from both
channels.
Press i or k to select AUDIO MODE.
Press j or l to select HI-FI.
HI-FI: The sound on the Hi-Fi audio track is played
back.
NORMAL: The sound on the normal audio track is
played back.
Press MENU to return to the normal screen.
Insert a cassette.
Press C PLAY.
Playback begins.
Output signals
The signals output from the AUDIO OUT jacks and RF OUT
to TV connector on the rear panel are as shown below.
