Operation
General Information
This manual is designed as a guide to operating and
maintaining your washer-extractor. It also serves as an
aid to troubleshooting.
Read and be sure you understand this manual and any
other literature included with your machine before
attempting to start the machine. For warranty
purposes, keep this manual, along with any other
literature and the wiring diagrams which accompany
the machine, in a safe place for ready reference. The
first copy is included with your machine. Additional
copies are available at a nominal charge.
Theory of Operation
NOTE: When power has been turned off from the
machine and then reapplied, the display will read
“WAIT” for approximately 30 seconds before the
display changes to “NEXT 00”.
Figure 1
U152R
1 Hot Spray Valve On 4 Cold Fill Valve On
2 Cold Spray Valve On 5 Low Level Fill Indicator
3 Hot Fill Valve On 6 High Level Fill Indicator
PHM543N
COLD / HOT / WARM /
LOW HIGH OVER
CLEAR DRAIN
STOP
ENTER
START
SOAK MEDIUM HIGH
PAUSE SPEED SPEED
ERASE
CYCLE
NUMBER
WASH / HEAT / SUPPLY
FLUSH RINSE
ADD
CYCLE
NUMBER /
ADVANCE
BUZZER
NO
REVERSE
DISPLAY
CYCLE
TEMP. /
1
2
5 4
3
6
