WATTBOX™ 600 Chassis Series Owners Manual
© 2013 Wattbox ™
Specifications
Outlets
Type NEMA 5-15
Number of Outlets 12
Always On 4 Outlets
IP Controlled 8 Outlets
AC Power
Line Voltage 120V, 60Hz
AC Input Connection IEC C-14
Power Cord Length 6 Feet
Circuit Breaker Rating 15A
UL Current Rating 12A
Voltage Protection Rating (UL 1449 3rd Edition) 500V
Joule Rating 6480 Joules
Surge Component Ceramic Encased MOV
Protection Modes L-N, L-G, N-G
Peak Impulse Current 396,000A
Disconnect Circuitry Yes
Thermal Fuse Yes
EMI / RFI Noise Filtration
Filter Banks 1 & 2 80 dB, 300 kHz to 100 MHz
Filter Bank 3 (High Current) 80 dB, 300 kHz to 100 MHz
Safe Voltage Disconnect
Over Voltage 138V AC +/- 5V AC
Under Voltage 88V AC +/- 5V AC
Cable / Satellite Circuit
Connections Gold Plated "F" Connector (1 Input and 1 Output)
Surge Component Gas Tube
Clipping Voltage 600V
Frequency Range 0MHz - 3.0 GHz
Insertion Loss < 0.5 dB
Shielded Yes
Bi-directional Yes
Phone / LAN Circuit
Connections RJ45 (1 Input and 1 Output)
Accepts RJ11 & RJ45
Surge Component Sidactor & MOV
Clipping Voltage RJ11:400V; RJ45:250V
Wires Protected 8 Wires
Operating Temperature Range 14 to104°F (-10 to +40°C)
UL Certifications UL 60950-1, UL 1449, UL 498, UL 497A/B, UL 1283
Dimensions 17” W x 3.5” H x 12.5” D
Connected Equipment Warranty $50,000
