Step 1, Step 2 – Luxor|H.Wilson PS4000 User Manual
Page 6
Step 1
After following the PS4000 Assembly guide to Step 3,
install 4 dowels (G) into the side panels (D,E).
Insert the side panels into the main unit.
Step 2
Install 4 dowels (G) into the top of the side
panels (C,D). Install the lock Catch (B) to the
middle shelf with 2 small screws (L).
Install the magnetic catch (N) to the side shelf (C)
with 2 small screws (L).
D
E
G
G
B
L
N
L
(A)
Detail - (A)
Middle Shelf (D)
Shelf Screws (M)
