Luxor|H.Wilson LMC2 User Manual
Instruction sheet model lmc2

Instruction Sheet
Model LMC2
Customer Service Dept
2245 Delany Rd
Waukegan, IL 60087
Ph: 847/244-1800 • 800/323-4656
Fax: 847/244-1818 • 800/327-1698
Step 1
Assemble bottim shelf and back panel with 3 screws.
Step 3
Install casters using
4 screws for each
caster.
Step 5
Install door using four screws.
Step 6
insert drawer and keyboard shelf.
Step 4
Assemble the cross brace to left and right side panel with 2 nuts and
2 washers
LLM
MC
C22
Step 2
Assemble left and right panel. Insert 2 screws to attach the panels to
the bottom shelf.
13Oct09
Step 7 For LMC2 ONLY
Insert shelf holder brackets into tabs at desired height on
inside of unit making sure all tabs are at the same height.
Place shelf inside on brackets.
