Instructions:
1. Take one of Tubular frame (B) and lay flat. Attach Blow molded tray (A) and Angle
brace (E) to frame using Hex bolt (F), Washer (G) and Nut (H). (see image #1 on next
page). * Do not tighten the screws all the way down.
2. Assemble 2 other molded trays with tubular frame as step 1.
3. Assemble another side of tubular frame to blow molded trays. (as step 1 & 2).
4. To attach the caster, inserts Ring seater (I) over the stem in the caster, and using
Screw (J) and Spring waster (K) fix with frame. Tighten casters with Hex wrench (L)
that is provided (see image #2 0n next page).
5. When unit is fully assembled, tighten screws all the way.
