LockeyUSA V Series - Manual (Page 2)

Install extrusion splice "from kit"
4
SubAssembly partially out
Slide Center Case/Pushpad
5
2
3
7
Mounting Endcap Bracket
Install Fascia when
back into extrusion.
Install Filler Splice "from kit"
Slide Filler Plate
SubAssembly
(DO NOT REMOVE)
Loosen set screw
Hand tighten set screw
after kit is installed
Approximately 3"
101278 Page 2 OF 3
Narrow Stile RIM Door Kit Installation
Slide Filler Plate
partially out
SubAssembly
1
Slide Center Case/Pushpad
SubAssembly back in place
6
