Installation and Quick Start
17
Quick Configuration
Control console
After you log on at the control console, as described in “Local
access to the control console” on page 15 or “Remote access to
the control console” on page 15:
1. Choose Network from the Control Console menu.
2. Choose
TCP/IP
from the Network menu.
3. If you are not using a
BOOTP or DHCP
server to
configure the
TCP/IP
settings, select the Boot Mode
menu. Select Manual boot mode, and then press
E
SC
to
return to the
TCP/IP
menu. (Changes will take effect
when you log out.)
4. Set the System
IP
, Subnet Mask, and Default Gateway
address values.
5. Press
C
TRL
-C
to exit to the Control Console menu.
6. Log out (option 4 in the Control Console menu).
Note
If you disconnected a cable during the
procedure described in “Local access to the
control console” on page 15, reconnect that
cable and restart the associated service.
