LockeyUSA 2835 - Manual (Page 2)

Step 8: Using the Lockey 2835
1. When the door is closed the system will lock automatically.
2. From the inside, unlock using the Lever Handle.
3. From the outside, unlock by pressing ‘C’ (CLEAR), followed by
your User Code.
4. The Lockey 2835 is equipped with a PASSAGE FUNCTION,
allowing you to leave the door unlocked.
- To enable the passage function, press ‘C’ (CLEAR),
then ‘Y’ (PASSAGE), followed by your User Code.
- To clear the passage function, press ‘Y’ (PASSAGE),
followed by ‘C’ (CLEAR).
- To disable the PASSAGE FUNCTION, you may remove
the ‘Y’ (PASSAGE) tumbler, leaving that slot empty.
IMPORTANT: Always press and hold the ‘C’ Button when removing
and inserting Tumblers. Refer to ‘How to Change Code’ instructions
below.
ENABLE PASSAGE MODE (Unlocked):
PRESS ‘C’  PRESS ‘Y’  Enter User Code
DISABLE PASSAGE MODE (Auto-Lock):
PRESS ‘Y’  PRESS ‘C’
-OR-
REMOVE ‘Y’ Pin (Tumbler) to disable
Passage Mode permanently.
Step 7 cont: Install the Lockey 2835
4. Insert the Spindle (#7) into the Outside
Body (#1) ensuring it’s
in the proper position.
(SEE FIGURES BELOW)
5. Using a screwdriver, secure
the lock to the door with
the Screws (#9 or #10).
Screw length dependent on
door thickness.
6. Test the operation of the latch by turning
the inside lever.
7. Locate position where latch strikes door frame
And install Strike Plate (#5) and Mortised Striker (#6).
IMPORTANT: SPINDLE POSITION
RIGHT-HAND DOORS: From inside,
place spindle through latch, into the
Outside Body (#1) in the 2:00/8:00
position as shown to right.
LEFT-HAND DOORS: From inside,
place spindle through latch, into the
Outside Body (#1) in the 10:00/4:00
position as shown to right.
6. Replace the cover plate and secure with four (4) Red Screws,
using a #2 screwdriver.
7. TEST CODE before installing/re-installing lock.
4. While holding the ‘C’ BUTTON, remove/add CODE (Red) and NON-CODE
(Blue) Tumblers to create your desired code.
Ex: 3 Red = 3-Digit Code / 6 Red = 6-Digit Code
IMPORTANT: Ensure notched side of tumbler fits into slot. (Below – Far Right).
5. After changing your code, release the ‘C’ BUTTON to secure the tumblers
in place.
3. PRESS & HOLD ‘C’ BUTTON to release tumblers.
IMPORTANT: ‘C’ Button must be pressed and held down when removing
and inserting tumblers. Failure to do so will damage the lock and void
the warranty.
Lockey 2835 Lever
How to Change Code
1. Using a #2 screwdriver, remove the four (4) Red Screws.
2. Carefully remove cover plate.
WARNING: Springs are attached to plate.
RED = CODE TUMBLERS
BLUE = NON-CODE TUMBLERS
‘C’ = CLEAR (DO NOT REMOVE)
‘Y’ = PASSAGE (‘Y’ Tumbler may be removed to
disable PASSAGE FUNCTION)
WARNING:
Do NOT force tumblers into position!
